Toyota Crown
2010-09 → 2012-12 · chassis GRS202 · catalogue 3312C0 · General
Supported model
Data version 2013-01
Dashed callouts are standard fasteners the factory draws but does not list
as separate parts — there is no part number behind them.
| Part number | Description | Fitment | Price | |
|---|---|---|---|---|
| 47101A — Spring(FOR BRAKE PEDAL RETURN) | ||||
| 90507-13009 |
Spring(FOR BRAKE PEDAL RETURN)
2010-09 → 2012-12
ended
|
GRS202 | — | |
| 47110 — Support Assy, Brake Pedal | ||||
| 47110-30452 |
Support Assy, Brake Pedal
2010-09 → 2012-12
ended
|
GRS202 | — | |
| 47121 — Pad, Brake Pedal | ||||
| 47121-50020 |
Pad, Brake Pedal
2010-09 → 2012-12
ended
|
GRS202 | — | |
| 47264A — Pin(FOR PUSH ROD) | ||||
| 90249-06180 |
Pin(FOR PUSH ROD)
2010-09 → 2012-12
ended
|
GRS202 | — | |
No quantity column: the factory catalogue records which parts a vehicle
takes, never how many.
