Toyota Crown
2010-09 → 2012-12 · chassis GRS202 · catalogue 3312C0 · General
Supported model
Data version 2013-01
Dashed callouts are standard fasteners the factory draws but does not list
as separate parts — there is no part number behind them.
| Part number | Description | Fitment | Price | |
|---|---|---|---|---|
| 51451C — Grommet(FOR ENGINE UNDER COVER) | ||||
| 90189-06193 |
Grommet(FOR ENGINE UNDER COVER)
2010-09 → 2011-07
ended
|
GRS202 | — | |
| 90189-06237 |
Grommet(FOR ENGINE UNDER COVER)
2011-08 → 2012-12
ended
|
GRS202 | — | |
| 51451F — Grommet, NO.1 | ||||
| 90189-06193 |
Grommet, NO.1
2010-09 → 2011-07
ended
|
GRS202 | — | |
| 90189-06237 |
Grommet, NO.1
2011-08 → 2012-12
ended
|
GRS202 | — | |
| 51451G — Grommet, NO.2 | ||||
| 90189-06193 |
Grommet, NO.2
2010-09 → 2011-07
ended
|
GRS202 | — | |
| 90189-06237 |
Grommet, NO.2
2011-08 → 2012-12
ended
|
GRS202 | — | |
| 52131A — Reinforcement, Front Bumper | ||||
| 52131-30290 |
Reinforcement, Front Bumper
2010-09 → 2012-12
ended
|
GRS202 | — | |
| 52161C — Piece, Front Bumper | ||||
| 52161-16010 |
Piece, Front Bumper
2010-09 → 2012-12
ended
|
GRS202 | — | |
| 52535 — Retainer, Front Bumper Side, RH | ||||
| 52535-30200 |
Retainer, Front Bumper Side, RH
2010-09 → 2012-12
ended
|
GRS202 | — | |
| 52535C — Retainer, Front Bumper Side | ||||
| 52535-50060 |
Retainer, Front Bumper Side
2010-09 → 2012-12
ended
|
GRS202 | — | |
| 52536 — Retainer, Front Bumper Side, LH | ||||
| 52536-30200 |
Retainer, Front Bumper Side, LH
2010-09 → 2012-12
ended
|
GRS202 | — | |
| 52611 — Absorber, Front Bumper Energy | ||||
| 52611-30380 |
Absorber, Front Bumper Energy
2010-09 → 2012-12
ended
|
GRS202 | — | |
| 53119E — Protector, Radiator Grille | ||||
| 53119-12150 |
Protector, Radiator Grille
2010-09 → 2012-12
ended
|
GRS202 | — | |
No quantity column: the factory catalogue records which parts a vehicle
takes, never how many.
