Toyota Crown
2010-09 → 2012-12 · chassis GRS202 · catalogue 3312C0 · General
Supported model
Data version 2013-01
Dashed callouts are standard fasteners the factory draws but does not list
as separate parts — there is no part number behind them.
| Part number | Description | Fitment | Price | |
|---|---|---|---|---|
| 52114A — Bracket, Front Bumper Extension Mounting | ||||
| 52114-30070 |
Bracket, Front Bumper Extension Mounting
2010-09 → 2012-12
ended
|
GRS202 | — | |
| 52119A — Cover, Front Bumper | ||||
| 52119-30994 |
Cover, Front Bumper
2010-09 → 2012-12
ended
|
GRS202 | — | |
| 52129B — Cover, Front Bumper, Lower | ||||
| 52129-30904 |
Cover, Front Bumper, Lower
2010-09 → 2012-12
ended
|
GRS202 | — | |
| 52144E — Stay, Front Bumper, Center | ||||
| 52144-30220 |
Stay, Front Bumper, Center
2010-09 → 2012-12
ended
|
GRS202 | — | |
| 52521A — Clip(FOR FRONT BUMPER RETAINER) | ||||
| 90467-08180 |
Clip(FOR FRONT BUMPER RETAINER)
2010-09 → 2012-12
ended
|
GRS202 | — | |
| 53112D — Grille, Radiator, Lower RH | ||||
| 53112-30340 |
Grille, Radiator, Lower RH
2010-09 → 2012-12
ended
|
GRS202 | — | |
| 53113D — Grille, Radiator, Lower LH | ||||
| 53113-30190 |
Grille, Radiator, Lower LH
2010-09 → 2012-12
ended
|
GRS202 | — | |
No quantity column: the factory catalogue records which parts a vehicle
takes, never how many.
