Toyota Crown
2010-09 → 2012-12 · chassis GRS202 · catalogue 3312C0 · General
Supported model
Data version 2013-01
Dashed callouts are standard fasteners the factory draws but does not list
as separate parts — there is no part number behind them.
| Part number | Description | Fitment | Price | |
|---|---|---|---|---|
| 55714C — Panel, Cowl Top Side, LH | ||||
| 55714-30110 |
Panel, Cowl Top Side, LH
2010-09 → 2012-12
ended
|
GRS202 | — | |
| 61038A — Reinforcement Sub-assy, Center Body Pillar, LH | ||||
| 61038-30110 |
Reinforcement Sub-assy, Center Body Pillar, LH
2010-09 → 2012-12
ended
|
GRS202 | — | |
| 61064C — Trough Sub-assy, Luggage Door Opening, Front LH | ||||
| 61064-30040 |
Trough Sub-assy, Luggage Door Opening, Front LH
2010-09 → 2012-12
ended
|
GRS202 | — | |
| 61102 — Panel Sub-assy, Cowl Side, LH | ||||
| 61102-30010 |
Panel Sub-assy, Cowl Side, LH
2010-09 → 2012-12
ended
|
GRS202 | — | |
| 61107B — Reinforce Sub-assy, Front Body Pillar, Upper LH | ||||
| 61107-30902 |
Reinforce Sub-assy, Front Body Pillar, Upper LH
2010-09 → 2012-12
ended
|
GRS202 | — | |
| 61132B — Pillar, Front Body, Outer LH | ||||
| 61132-30320 |
Pillar, Front Body, Outer LH
2010-09 → 2012-12
ended
|
GRS202 | — | |
| 61146B — Gusset, Front Body Pillar, Lower LH | ||||
| 61146-30060 |
Gusset, Front Body Pillar, Lower LH
2010-09 → 2012-12
ended
|
GRS202 | — | |
| 61174A — Reinforcement, Front Body Pillar, Upper Inner LH | ||||
| 61174-30160 |
Reinforcement, Front Body Pillar, Upper Inner LH
2010-09 → 2012-12
ended
|
GRS202 | — | |
| 61204 — Rail Sub-assy, Roof Side, Inner LH | ||||
| 61204-30110 |
Rail Sub-assy, Roof Side, Inner LH
2010-09 → 2012-12
ended
|
GRS202 | — | |
| 61206 — Rail Sub-assy, Roof Side, Inner Rear LH | ||||
| 61206-30040 |
Rail Sub-assy, Roof Side, Inner Rear LH
2010-09 → 2012-12
ended
|
GRS202 | — | |
| 61212 — Rail, Roof Side, Outer LH | ||||
| 61212-30290 |
Rail, Roof Side, Outer LH
2010-09 → 2012-12
ended
|
GRS202 | — | |
| 61226A — Rail, Roof Side Outer Upper NO.1, LH | ||||
| 61226-30040 |
Rail, Roof Side Outer Upper NO.1, LH
2010-09 → 2012-12
ended
|
GRS202 | — | |
| 61308 — Pillar Sub-assy, Center Body, Inner LH | ||||
| 61308-30020 |
Pillar Sub-assy, Center Body, Inner LH
2010-09 → 2012-12
ended
|
GRS202 | — | |
| 61312B — Pillar, Center Body, Outer LH | ||||
| 61312-30370 |
Pillar, Center Body, Outer LH
2010-09 → 2012-12
ended
|
GRS202 | — | |
| 61402C — Panel Sub-assy, Rocker, Outer LH | ||||
| 61402-30280 |
Panel Sub-assy, Rocker, Outer LH
2010-09 → 2012-12
ended
|
GRS202 | — | |
| 61404E — Reinforce Sub-assy, Rocker, Outer LH | ||||
| 61404-30010 |
Reinforce Sub-assy, Rocker, Outer LH
2010-09 → 2012-12
ended
|
GRS202 | — | |
| 61608D — Panel, Quarter Wheel House, Inner LH | ||||
| 61608-30260 |
Panel, Quarter Wheel House, Inner LH
2010-09 → 2012-12
ended
|
GRS202 | — | |
| 61612 — Panel, Quarter, LH | ||||
| 61612-30A40 |
Panel, Quarter, LH
2010-09 → 2012-12
ended
|
GRS202 | — | |
| 61626G — Extension, Quarter Panel, Rear LH | ||||
| 61626-30090 |
Extension, Quarter Panel, Rear LH
2010-09 → 2012-12
ended
|
GRS202 | — | |
| 61632A — Panel, Quarter Wheel House, Outer LH | ||||
| 61632-30220 |
Panel, Quarter Wheel House, Outer LH
2010-09 → 2012-12
ended
|
GRS202 | — | |
| 61642C — Gusset, Quarter Wheel House, Front LH | ||||
| 61642-30050 |
Gusset, Quarter Wheel House, Front LH
2010-09 → 2012-12
ended
|
GRS202 | — | |
| 61712 — Panel, Roof Side, Outer LH | ||||
| 61712-30160 |
Panel, Roof Side, Outer LH
2010-09 → 2012-12
ended
|
GRS202 | — | |
| 61732B — Panel, Roof Side, Inner LH | ||||
| 61732-30260 |
Panel, Roof Side, Inner LH
2010-09 → 2012-12
ended
|
GRS202 | — | |
| 61736A — Panel, Roof Side, Inner Rear LH | ||||
| 61736-30100 |
Panel, Roof Side, Inner Rear LH
2010-09 → 2012-12
ended
|
GRS202 | — | |
| 62151B — Pad, Cowl Side Silencer | ||||
| 62151-20160 |
Pad, Cowl Side Silencer
2010-09 → 2012-12
ended
|
GRS202 | — | |
| 62554B — Pad, Pillar, NO.4 | ||||
| 62554-30010 |
Pad, Pillar, NO.4
2010-09 → 2012-12
ended
|
GRS202 | — | |
| 64202A — Strainer Sub-assy, Package Tray TO Floor, LH | ||||
| 64202-30220 |
Strainer Sub-assy, Package Tray TO Floor, LH
2010-09 → 2012-12
ended
|
GRS202 | — | |
| 65638 — Liner, Rear Wheel House, LH | ||||
| 65638-30070 |
Liner, Rear Wheel House, LH
2010-09 → 2012-12
ended
|
GRS202 | — | |
No quantity column: the factory catalogue records which parts a vehicle
takes, never how many.
