Toyota Crown
2010-09 → 2012-12 · chassis GRS202 · catalogue 3312C0 · General
Supported model
Data version 2013-01
Dashed callouts are standard fasteners the factory draws but does not list
as separate parts — there is no part number behind them.
| Part number | Description | Fitment | Price | |
|---|---|---|---|---|
| 73023 — Plate Sub-assy, Front Shoulder Belt Anchor, RH | ||||
| 73023-53010-A2 note |
Plate Sub-assy, Front Shoulder Belt Anchor, RH
2010-09 → 2012-12
ended
|
GRS202 | — | |
| 73023-53010-B1 note |
Plate Sub-assy, Front Shoulder Belt Anchor, RH
2010-09 → 2012-04
ended
|
GRS202 | — | |
| 73024 — Plate Sub-assy, Front Shoulder Belt Anchor, LH | ||||
| 73024-53010-A2 note |
Plate Sub-assy, Front Shoulder Belt Anchor, LH
2010-09 → 2012-12
ended
|
GRS202 | — | |
| 73024-53010-B1 note |
Plate Sub-assy, Front Shoulder Belt Anchor, LH
2010-09 → 2012-04
ended
|
GRS202 | — | |
| 73173 — Cover, Front Seat Belt Hole, RH | ||||
| 73173-30070-A1 note |
Cover, Front Seat Belt Hole, RH
2010-09 → 2012-12
ended
|
GRS202 | — | |
| 73173-30070-B0 note |
Cover, Front Seat Belt Hole, RH
2010-09 → 2012-12
ended
|
GRS202 | — | |
| 73174 — Cover, Front Seat Belt Hole, LH | ||||
| 73174-30070-A1 note |
Cover, Front Seat Belt Hole, LH
2010-09 → 2012-12
ended
|
GRS202 | — | |
| 73174-30070-B0 note |
Cover, Front Seat Belt Hole, LH
2010-09 → 2012-12
ended
|
GRS202 | — | |
| 73200A — Adjuster Assy, Front Shoulder Belt Anchor | ||||
| 73200-53010 |
Adjuster Assy, Front Shoulder Belt Anchor
2010-09 → 2012-12
ended
|
GRS202 | — | |
| 73210 — Belt Assy, Front Seat Outer, RH | ||||
| 73210-30C60-A1 note |
Belt Assy, Front Seat Outer, RH
2010-09 → 2012-12
ended
|
GRS202 | — | |
| 73210-30C60-B2 note |
Belt Assy, Front Seat Outer, RH
2010-09 → 2012-12
ended
|
GRS202 | — | |
| 73219 — Stopper, Tongue Plate | ||||
| 73219-33010 note |
Stopper, Tongue Plate
2010-09 → 2012-12
ended
|
GRS202 | — | |
| 73219-33020 note |
Stopper, Tongue Plate
2010-09 → 2012-12
ended
|
GRS202 | — | |
| 73219-33030 note |
Stopper, Tongue Plate
2010-09 → 2012-12
ended
|
GRS202 | — | |
| 73220 — Belt Assy, Front Seat Outer, LH | ||||
| 73220-30C20-A1 note |
Belt Assy, Front Seat Outer, LH
2010-09 → 2012-12
ended
|
GRS202 | — | |
| 73220-30C20-B2 note |
Belt Assy, Front Seat Outer, LH
2010-09 → 2012-12
ended
|
GRS202 | — | |
| 73223D — Cover, Front Seat Belt Retractor, RH | ||||
| 73223-30130 |
Cover, Front Seat Belt Retractor, RH
2010-09 → 2012-12
ended
|
GRS202 | — | |
| 73224B — Cover, Front Seat Belt Retractor, LH | ||||
| 73224-30100 |
Cover, Front Seat Belt Retractor, LH
2010-09 → 2012-12
ended
|
GRS202 | — | |
| 73230 — Belt Assy, Front Seat Inner, RH | ||||
| 73230-30A40-A0 note |
Belt Assy, Front Seat Inner, RH
2010-09 → 2012-12
ended
|
GRS202 | — | |
| 73230-30A40-B0 note |
Belt Assy, Front Seat Inner, RH
2010-09 → 2012-12
ended
|
GRS202 | — | |
| 73240 — Belt Assy, Front Seat Inner, LH | ||||
| 73230-30A60-A0 note |
Belt Assy, Front Seat Inner, LH
2010-09 → 2012-12
ended
|
GRS202 | — | |
| 73230-30A60-B0 note |
Belt Assy, Front Seat Inner, LH
2010-09 → 2012-12
ended
|
GRS202 | — | |
No quantity column: the factory catalogue records which parts a vehicle
takes, never how many.
