Toyota Alphard Hev/Phev
2024-05 → present · chassis AZSH38,39 · catalogue 33C210 · General
Supported model
Data version 2024-05
| Part number | Description | Fitment | Price | |
|---|---|---|---|---|
| 42601 — Wheel, Disc | ||||
| 42611-30K60 note |
Wheel, Disc
2024-05 → —
|
AZSH38 M | — | |
| 42611-30L50 note |
Wheel, Disc
2024-09 → —
|
AZSH39 | — | |
| 42611-30M50 note |
Wheel, Disc
2024-05 → —
|
AZSH38 G | — | |
| 42611-30M60 note |
Wheel, Disc
2024-05 → —
|
AZSH38 G | — | |
| 42601A — Wheel, Disc (FOR SPARE) | ||||
| 4261B-30010 note |
Wheel, Disc (FOR SPARE)
2024-05 → —
|
AZSH38 | — | |
| 42601B — Bolt, Hub (FOR AXLE) | ||||
| 90942-02103 |
Bolt, Hub (FOR AXLE)
2024-05 → —
|
AZSH3# | — | |
| 42603 — Ornament Sub-assy, Wheel Hub | ||||
| 42603-42170 note |
Ornament Sub-assy, Wheel Hub
2024-05 → —
|
AZSH38 | — | |
| 42607 — Valve Sub-assy, Tire Pressure Monitor | ||||
| 42607-42050 note |
Valve Sub-assy, Tire Pressure Monitor
2024-05 → —
|
AZSH38 M | — | |
| 42607-47020 note |
Valve Sub-assy, Tire Pressure Monitor
2024-05 → —
|
AZSH3# G | — | |
| 42607D — Valve, Tire Pressure Monitor | ||||
| 90942-05043 note |
Valve, Tire Pressure Monitor
2024-05 → —
|
AZSH38 M | — | |
| 90942-05047 note |
Valve, Tire Pressure Monitor
2024-05 → —
|
AZSH3# G | — | |
| 42611J — Valve (FOR TUBELESS TIRE SPARE) | ||||
| 90942-05009 note |
Valve (FOR TUBELESS TIRE SPARE)
2024-05 → —
|
AZSH38 | — | |
| 42621 — Cap, Wheel | ||||
| 42602-30111 note |
Cap, Wheel
2024-09 → —
|
AZSH39 | — | |
No quantity column: the factory catalogue records which parts a vehicle
takes, never how many.
