Toyota Avalon

2012-10 → 2018-04 · chassis GSX40 · catalogue 361340 · General

Supported model Data version 2018-11
Parts groups Model variants Characteristics Frame ranges Catalogue groups Illustration notes Newest parts Spec codes

Hood & Front Fender

21 part groups · 2 illustrations

Illustrations

Figure 537185A 537185A 2012-10 → — Figure 537186A 537186A 2012-10 → —

Part groups

PNCDescription
53301 Hood Sub-assy
53341B Insulator, Hood
53341C Clip(FOR HOOD INSULATOR)
53381 Seal, Hood TO Radiator Support
53381A Clip(FOR HOOD TO RADIATOR SUPPORT SEAL)
53388D Seal, Hood TO Front Fender, RH
53389B Seal, Hood TO Front Fender, LH
53811A Panel, Front Fender, RH
53812C Panel, Front Fender, LH
53825A Protector, Front Fender, Upper RH
53826A Protector, Front Fender, Upper LH
53835C Bracket, Front Side Panel, RH
53836B Bracket, Front Side Panel, LH
53875A Liner, Front Fender, RH
53875C Clip, Front Fender Liner
53876A Liner, Front Fender, LH
53879A Retainer, Front Fender Liner
53882B Seal, Front Fender, RH
53882F Seal, Front Fender
53882N Clip(FOR FRONT FENDER SEAL)
53883B Seal, Front Fender, LH
PNC is the six-character part-group number the factory catalogue files parts under. Every part on a drawing belongs to one.
