Toyota Avalon

2000-04 → 2005-06 · chassis MCX10 · catalogue 362210 · General

Discontinued model Data version 2006-04

Roof Panel & Back Window Glass

39 part groups · 2 illustrations

PNC	Description
56115B	Stopper, Back Window Glass, NO.1
63102A	Panel Sub-assy, Windshield Header
63111	Panel, Roof
63118	Support, Roof Panel, RH
63119	Support, Roof Panel, LH
63133A	Frame, Back Window, Upper
63141H	Reinforcement, Roof Panel, Center
63143B	Reinforcement, Roof Panel, NO.3
63144A	Reinforcement, Roof Panel, NO.4
63201G	Glass Sub-assy, Sliding Roof
63202H	Rail Sub-assy, Slide Roof
63206G	Gear Sub-assy, Sliding Roof Drive
63209	Panel Sub-assy, Roof Wind Deflector
63214F	Channel, Roof Drip, Rear
63217G	Garnish, Sliding Roof Side, RH
63218A	Hose(FOR SLIDING ROOF OR REMOVABLE ROOF DRAIN)
63218G	Garnish, Sliding Roof Side, LH
63218H	Hose, Sliding Roof Drain
63219A	Garnish, Sliding Roof, Rear
63223	Cable, Sliding Roof Drive, RH
63224	Cable, Sliding Roof Drive, LH
63233F	Frame, Removable Roof Housing
63237A	Plate, Removable Roof Female, Rear RH
63239	Stopper, Sliding Roof Panel
63241A	Bracket, Sliding Roof Housing Front Mounting, RH
63242A	Bracket, Sliding Roof Housing Front Mounting, LH
63245D	Bracket, Sliding Roof Housing Rear Mounting, RH
63246C	Bracket, Removable Roof, NO.2
63265B	Gear, Sliding Roof Drive
63267A	Protector, Sliding Roof Weatherstrip, RH
63625	Block, Sliding Roof Guide, RH
63626	Block, Sliding Roof Guide, LH
63635A	Garnish, Sliding Roof, Front
64101	Panel Sub-assy, Upper Back
64167B	Cover, Upper Back Panel Hole, NO.3
64225B	Hanger, Rear Seat Cushion Support
64226D	Hanger, Rear Seat Cushion Support, NO.2
64811	Glass, Back Window
64818	Spacer, Back Window Glass

PNC is the six-character part-group number the factory catalogue files parts under. Every part on a drawing belongs to one.
