Toyota Yaris Cross
2023-06 → present · chassis NGC200,NYC200 · catalogue 514210 · General
Supported model
Data version 2023-09
Interior Lamp
7 part groups · 2 illustrations
Part groups
| PNC | Description |
|---|---|
| 63231 | Bracket, Room Lamp |
| 81080M | Lamp Assy, Interior Illumination, NO.1 |
| 8121AD | Lamp, Led Illumination, RH |
| 8122AB | Lamp, Led Illumination, LH |
| 81240 | Lamp Assy, Room, NO.1 |
| 81250 | Lamp Assy, Room, NO.2 |
| 81260A | Lamp Assy, Map |
PNC is the six-character part-group number the factory catalogue files
parts under. Every part on a drawing belongs to one.
