Toyota Highlander (CHINA)

2015-03 → present · chassis ASU5#,GSU55 · catalogue 520320 · General

Supported model Data version 2018-05
Parts groups Model variants Characteristics Frame ranges Catalogue groups Illustration notes Newest parts Spec codes
Exploded illustration 165892B 8404 — not listed in this catalogue 16261 — HOSE, WATER BY-PASS (3 parts) 16261A — CLAMP OR CLIP, HOSE(FOR WATER BY-PASS HOSE) (5 parts) 16264 — HOSE, WATER BY-PASS, NO.2 (3 parts) 16264E — CLIP(FOR WATER BY-PASS HOSE NO.2) (2 parts) 16264E — CLIP(FOR WATER BY-PASS HOSE NO.2) (2 parts) 16264H — CLIP(FOR WATER BY-PASS HOSE NO.3) (2 parts) 16267 — HOSE, WATER BY-PASS, NO.3 (1 parts) 16321 — INLET, WATER (5 parts) 16322 — PIPE, WATER INLET (1 parts) 16323 — HOUSING, WATER INLET (3 parts) 16325 — GASKET, WATER INLET HOUSING, NO.1 (3 parts) 16326 — GASKET, WATER INLET HOUSING, NO.2 (3 parts) 16331 — OUTLET, WATER (1 parts) 16331A — THERMOSTAT (5 parts) 16341 — GASKET, WATER OUTLET (3 parts) 16341 — GASKET, WATER OUTLET (3 parts) 9091009127 — not listed in this catalogue 9155180620 — not listed in this catalogue 9155180660 — not listed in this catalogue 9167180614 — not listed in this catalogue 9212280616 — not listed in this catalogue 9415180600 — not listed in this catalogue 9415180600 — not listed in this catalogue 9415180600 — not listed in this catalogue 9415180600 — not listed in this catalogue 9613642701 — not listed in this catalogue 9613642701 — not listed in this catalogue 9676124019 — not listed in this catalogue 9676124021 — not listed in this catalogue 8404 — not listed in this catalogue 8716 — not listed in this catalogue 8716 — not listed in this catalogue 2211 — not listed in this catalogue 2211 — not listed in this catalogue
165892B · 16 callouts, 19 unlisted Full size ↗
Dashed callouts are standard fasteners the factory draws but does not list as separate parts — there is no part number behind them.
40 parts on this figure
Part number Description Fitment Price
16261 — Hose, Water By-pass
16261-0V070 Hose, Water By-pass
2015-03 → 2018-03 ended
8ARFTS ASU5# —
16261-31050 Hose, Water By-pass
2015-03 → 2017-10 ended
2GRFE GSU55 —
16261-0V070 Hose, Water By-pass
2018-03 → —
8ARFTS ASU5# —
16261A — Clamp OR Clip, Hose(FOR WATER BY-PASS HOSE)
90466-C0004 note Clamp OR Clip, Hose(FOR WATER BY-PASS HOSE)
2015-03 → 2018-03 ended
8ARFTS ASU5# —
96136-52101 note Clamp OR Clip, Hose(FOR WATER BY-PASS HOSE)
2015-03 → 2018-03 ended
8ARFTS ASU5# —
96137-41501 Clamp OR Clip, Hose(FOR WATER BY-PASS HOSE)
2015-03 → 2017-10 ended
2GRFE GSU55 —
90466-C0004 note Clamp OR Clip, Hose(FOR WATER BY-PASS HOSE)
2018-03 → —
8ARFTS ASU5# —
96136-52101 note Clamp OR Clip, Hose(FOR WATER BY-PASS HOSE)
2018-03 → —
8ARFTS ASU5# —
16264 — Hose, Water By-pass, NO.2
16264-31081 Hose, Water By-pass, NO.2
2015-03 → 2017-10 ended
2GRFE GSU55 —
16264-36090 Hose, Water By-pass, NO.2
2015-03 → 2018-03 ended
8ARFTS ASU5# —
16264-36090 Hose, Water By-pass, NO.2
2018-03 → —
8ARFTS ASU5# —
16264E — Clip(FOR WATER BY-PASS HOSE NO.2)
90466-C0026 note Clip(FOR WATER BY-PASS HOSE NO.2)
2015-03 → 2017-10 ended
2GRFE GSU55 —
96137-41501 note Clip(FOR WATER BY-PASS HOSE NO.2)
2015-03 → 2017-10 ended
2GRFE GSU55 —
16264H — Clip(FOR WATER BY-PASS HOSE NO.3)
90466-C0026 note Clip(FOR WATER BY-PASS HOSE NO.3)
2015-03 → 2017-10 ended
2GRFE GSU55 —
96137-41501 note Clip(FOR WATER BY-PASS HOSE NO.3)
2015-03 → 2017-10 ended
2GRFE GSU55 —
16267 — Hose, Water By-pass, NO.3
16267-31040 Hose, Water By-pass, NO.3
2015-03 → 2017-10 ended
2GRFE GSU55 —
16321 — Inlet, Water
16321-31030 Inlet, Water
2015-03 → 2017-10 ended
2GRFE GSU55 —
16321-36040 Inlet, Water
2017-07 → 2017-08 ended
8ARFTS ASU5# —
16321-36041 Inlet, Water
2017-09 → 2018-03 ended
8ARFTS ASU5# —
16321-36070 Inlet, Water
2015-03 → 2017-06 ended
8ARFTS ASU5# —
16321-36041 Inlet, Water
2018-03 → —
8ARFTS ASU5# —
16322 — Pipe, Water Inlet
16322-31020 Pipe, Water Inlet
2015-03 → 2017-10 ended
2GRFE GSU55 —
16323 — Housing, Water Inlet
16032-36060 Housing, Water Inlet
2015-03 → 2018-03 ended
8ARFTS ASU5# —
16323-31040 Housing, Water Inlet
2015-03 → 2017-10 ended
2GRFE GSU55 —
16032-36060 Housing, Water Inlet
2018-03 → —
8ARFTS ASU5# —
16325 — Gasket, Water Inlet Housing, NO.1
16325-36051 Gasket, Water Inlet Housing, NO.1
2015-03 → 2018-03 ended
8ARFTS ASU5# —
16325-62010 Gasket, Water Inlet Housing, NO.1
2015-03 → 2017-10 ended
2GRFE GSU55 —
16325-36051 Gasket, Water Inlet Housing, NO.1
2018-03 → —
8ARFTS ASU5# —
16326 — Gasket, Water Inlet Housing, NO.2
16325-31010 Gasket, Water Inlet Housing, NO.2
2015-03 → 2017-10 ended
2GRFE GSU55 —
16326-36030 Gasket, Water Inlet Housing, NO.2
2015-03 → 2018-03 ended
8ARFTS ASU5# —
16326-36030 Gasket, Water Inlet Housing, NO.2
2018-03 → —
8ARFTS ASU5# —
16331 — Outlet, Water
16331-31140 Outlet, Water
2015-03 → 2017-10 ended
2GRFE GSU55 —
16331A — Thermostat
90916-03140 note Thermostat
2015-03 → 2017-10 ended
2GRFE GSU55 —
90916-03154 note Thermostat
2015-03 → 2018-03 ended
8ARFTS ASU5# —
90916-03156 note Thermostat
2015-03 → 2018-03 ended
8ARFTS ASU5# —
90916-03154 note Thermostat
2018-03 → —
8ARFTS ASU5# —
90916-03156 note Thermostat
2018-03 → —
8ARFTS ASU5# —
16341 — Gasket, Water Outlet
16341-31010 Gasket, Water Outlet
2015-03 → 2017-10 ended
2GRFE GSU55 —
16341-36020 Gasket, Water Outlet
2015-03 → 2018-03 ended
8ARFTS ASU5# —
16341-36020 Gasket, Water Outlet
2018-03 → —
8ARFTS ASU5# —
No quantity column: the factory catalogue records which parts a vehicle takes, never how many.
