Toyota Highlander (CHINA)

2015-03 → present · chassis ASU5#,GSU55 · catalogue 520320 · General

Supported model Data version 2018-05
Parts groups Model variants Characteristics Frame ranges Catalogue groups Illustration notes Newest parts Spec codes

Caution Plate (EXTERIOR & INTERIOR)

12 part groups · 2 illustrations

Illustrations

Figure 744060D 744060D 2015-03 → — Figure 744061A 744061A 2015-03 → —

Part groups

PNCDescription
11285A Label, Coolant System Notice
11285F Label, Coolant System Caution
16793B Label, Cooling Fan Information
41992 Label, Differential Notice
74515A Plate, Theft Warning
74528J Label, Power Back Door Caution
74529 Plate, Child Proof OR Child Protector Lock Caution
74545B Label, Tire Carrier Notice, NO.2
74579A Label, Unleaded Fuel Information
74596A Label, Side Airbag Caution
74751 Label, Tire Pressure Information
88723H Label, Cooler Service Caution
PNC is the six-character part-group number the factory catalogue files parts under. Every part on a drawing belongs to one.
