Toyota Harrier

2017-05 → 2020-05 · chassis ASU60 · catalogue 521340 · General

Supported model Data version 2020-06
Parts groups Model variants Characteristics Frame ranges Catalogue groups Illustration notes Newest parts Spec codes

Armrest & Visor

15 part groups · 2 illustrations

Illustrations

Figure 743782 743782 2017-05 → — Figure 743783C 743783C 2017-05 → —

Part groups

PNCDescription
74221 Cover, Door Armrest, RH
74222 Cover, Door Armrest, LH
74223 Cap, Door Armrest, RH
74224 Cap, Door Armrest, LH
74310 Visor Assy, RH
74320 Visor Assy, LH
74325 Cover, Visor Bracket
74348 Holder, Visor
74610A Grip Sub-assy, Assist
74611K Cover, Assist Grip, RH Front Side
74611L Cover, Assist Grip, RH Rear Side
74612G Cover, Assist Grip, LH Front Side
74612H Cover, Assist Grip, LH Rear Side
74614C Plate, Assist Grip Lock
74620B Grip Assy, Assist, Rear
PNC is the six-character part-group number the factory catalogue files parts under. Every part on a drawing belongs to one.
