Toyota Highlander/Kluger
2007-05 → 2013-12 · chassis GSU4# · catalogue 522320 · General
Supported model
Data version 2014-06
Dashed callouts are standard fasteners the factory draws but does not list
as separate parts — there is no part number behind them.
| Part number | Description | Fitment | Price | |
|---|---|---|---|---|
| 52161K — Piece, Front Bumper | ||||
| 52161-16010 |
Piece, Front Bumper
2007-05 → 2010-07
ended
|
GSU4# | — | |
| 52161-16010 |
Piece, Front Bumper
2010-07 → —
|
GSU4# | — | |
| 53111 — Grille, Radiator | ||||
| 53101-48160 note |
Grille, Radiator
2007-05 → 2010-07
ended
|
GSU4# STD | — | |
| 53101-48170 note |
Grille, Radiator
2007-05 → 2009-01
ended
|
GSU45 SPO | — | |
| 53101-48170 note |
Grille, Radiator
2007-05 → 2010-07
ended
|
GSU4# STD ARL | — | |
| 53101-48180 note |
Grille, Radiator
2007-05 → 2010-07
ended
|
GSU4# GD,LIMD | — | |
| 53101-48350 note |
Grille, Radiator
2010-07 → —
|
GSU4# ARL | — | |
| 53101-48360 note |
Grille, Radiator
2010-07 → —
|
GSU45 RUS | — | |
| 53145B — Clip, Radiator Grille Garnish | ||||
| 53145-60030 |
Clip, Radiator Grille Garnish
2010-07 → —
|
GSU4# | — | |
| 53395H — Seal, Hood TO Radiator Grille | ||||
| 53395-48050 |
Seal, Hood TO Radiator Grille
2010-07 → —
|
GSU4# | — | |
No quantity column: the factory catalogue records which parts a vehicle
takes, never how many.
