Toyota Lexus NX Series
2021-11 → present · chassis AAZA2#,AAZH2#,MAZA20,TAZA25 · catalogue 527220 · General
Supported model
Data version 2024-05
Dashed callouts are standard fasteners the factory draws but does not list
as separate parts — there is no part number behind them.
| Part number | Description | Fitment | Price | |
|---|---|---|---|---|
| 68750 — Hinge Assy, Rear Door, Upper RH | ||||
| 68750-20122 |
Hinge Assy, Rear Door, Upper RH
2024-03 → —
|
AAZH2#,MAZA20,TAZA25 | — | |
| 68750-20122 |
Hinge Assy, Rear Door, Upper RH
2024-03 → 2025-06
ended
|
AAZA2# | — | |
| 68750-20122 |
Hinge Assy, Rear Door, Upper RH
2021-11 → 2024-03
ended
|
AAZA2#,AAZH2#,MAZA20,TAZA25 CHI,EUR,GEN | — | |
| 68750-20122 |
Hinge Assy, Rear Door, Upper RH
2021-11 → 2024-05
ended
|
AAZH25,TAZA25 GCC | — | |
| 68760 — Hinge Assy, Rear Door, Upper LH | ||||
| 68760-20122 |
Hinge Assy, Rear Door, Upper LH
2024-03 → 2025-06
ended
|
AAZA2# | — | |
| 68760-20122 |
Hinge Assy, Rear Door, Upper LH
2024-03 → —
|
AAZH2#,MAZA20,TAZA25 | — | |
| 68760-20122 |
Hinge Assy, Rear Door, Upper LH
2021-11 → 2024-03
ended
|
AAZA2#,AAZH2#,MAZA20,TAZA25 CHI,EUR,GEN | — | |
| 68760-20122 |
Hinge Assy, Rear Door, Upper LH
2021-11 → 2024-05
ended
|
AAZH25,TAZA25 GCC | — | |
| 68770 — Hinge Assy, Rear Door, Lower RH | ||||
| 68770-33050 |
Hinge Assy, Rear Door, Lower RH
2024-03 → 2025-06
ended
|
AAZA2# | — | |
| 68770-33050 |
Hinge Assy, Rear Door, Lower RH
2024-03 → —
|
AAZH2#,MAZA20,TAZA25 | — | |
| 68770-33050 |
Hinge Assy, Rear Door, Lower RH
2021-11 → 2024-03
ended
|
AAZA2#,AAZH2#,MAZA20,TAZA25 CHI,EUR,GEN | — | |
| 68770-33050 |
Hinge Assy, Rear Door, Lower RH
2021-11 → 2024-05
ended
|
AAZH25,TAZA25 GCC | — | |
| 68780 — Hinge Assy, Rear Door, Lower LH | ||||
| 68780-33050 |
Hinge Assy, Rear Door, Lower LH
2024-03 → 2025-06
ended
|
AAZA2# | — | |
| 68780-33050 |
Hinge Assy, Rear Door, Lower LH
2024-03 → —
|
AAZH2#,MAZA20,TAZA25 | — | |
| 68780-33050 |
Hinge Assy, Rear Door, Lower LH
2021-11 → 2024-03
ended
|
AAZA2#,AAZH2#,MAZA20,TAZA25 CHI,EUR,GEN | — | |
| 68780-33050 |
Hinge Assy, Rear Door, Lower LH
2021-11 → 2024-05
ended
|
AAZH25,TAZA25 GCC | — | |
| 69803 — Regulator Sub-assy, Rear Door Window, RH | ||||
| 69803-78020 |
Regulator Sub-assy, Rear Door Window, RH
2024-03 → —
|
AAZH2#,MAZA20,TAZA25 | — | |
| 69803-78020 |
Regulator Sub-assy, Rear Door Window, RH
2024-03 → 2025-06
ended
|
AAZA2# | — | |
| 69803-78010 note |
Regulator Sub-assy, Rear Door Window, RH
2021-11 → 2023-05
ended
|
AAZA2#,AAZH2#,MAZA20,TAZA25 | — | |
| 69803-78020 note |
Regulator Sub-assy, Rear Door Window, RH
2023-06 → 2024-05
ended
|
AAZH26 RHD;AAZH26 LHD EUR;AAZA2#,AAZH20,21,25,MAZA20,TAZA25 | — | |
| 69803-78020 note |
Regulator Sub-assy, Rear Door Window, RH
2023-08 → 2024-05
ended
|
AAZH26 RHD;AAZH26 LHD EUR;AAZA2#,AAZH20,21,25,MAZA20,TAZA25 | — | |
| 69804 — Regulator Sub-assy, Rear Door Window, LH | ||||
| 69804-78020 |
Regulator Sub-assy, Rear Door Window, LH
2024-03 → 2025-06
ended
|
AAZA2# | — | |
| 69804-78020 |
Regulator Sub-assy, Rear Door Window, LH
2024-03 → —
|
AAZH2#,MAZA20,TAZA25 | — | |
| 69804-78010 note |
Regulator Sub-assy, Rear Door Window, LH
2021-11 → 2023-05
ended
|
AAZA2#,AAZH2#,MAZA20,TAZA25 | — | |
| 69804-78020 note |
Regulator Sub-assy, Rear Door Window, LH
2023-08 → 2024-05
ended
|
AAZH26 RHD;AAZH26 LHD EUR;AAZA2#,AAZH20,21,25,MAZA20,TAZA25 | — | |
| 69804-78020 note |
Regulator Sub-assy, Rear Door Window, LH
2023-06 → 2024-05
ended
|
AAZH26 RHD;AAZH26 LHD EUR;AAZA2#,AAZH20,21,25,MAZA20,TAZA25 | — | |
| 85710F — Motor Assy, Power Window Regulator, RH | ||||
| 85710-78040 |
Motor Assy, Power Window Regulator, RH
2024-03 → 2025-06
ended
|
AAZA2# | — | |
| 85710-78040 |
Motor Assy, Power Window Regulator, RH
2024-03 → —
|
AAZH2#,MAZA20,TAZA25 | — | |
| 85710-78040 note |
Motor Assy, Power Window Regulator, RH
2021-11 → 2024-05
ended
|
AAZH26 RHD;AAZH26 LHD EUR;AAZA2#,AAZH20,21,25,MAZA20,TAZA25 | — | |
| 85710-78040 note |
Motor Assy, Power Window Regulator, RH
2023-08 → 2024-05
ended
|
AAZH26 RHD;AAZH26 LHD EUR;AAZA2#,AAZH20,21,25,MAZA20,TAZA25 | — | |
| 85720E — Motor Assy, Power Window Regulator, LH | ||||
| 85720-78040 |
Motor Assy, Power Window Regulator, LH
2024-03 → 2025-06
ended
|
AAZA2# | — | |
| 85720-78040 |
Motor Assy, Power Window Regulator, LH
2024-03 → —
|
AAZH2#,MAZA20,TAZA25 | — | |
| 85720-78040 note |
Motor Assy, Power Window Regulator, LH
2021-11 → 2024-05
ended
|
AAZH26 RHD;AAZH26 LHD EUR;AAZA2#,AAZH20,21,25,MAZA20,TAZA25 | — | |
| 85720-78040 note |
Motor Assy, Power Window Regulator, LH
2023-08 → 2024-05
ended
|
AAZH26 RHD;AAZH26 LHD EUR;AAZA2#,AAZH20,21,25,MAZA20,TAZA25 | — | |
No quantity column: the factory catalogue records which parts a vehicle
takes, never how many.
