Toyota C-hr

2023-10 → present · chassis MAXH2#,ZYX20 · catalogue 528220 · General

Supported model Data version 2023-12
Parts groups Model variants Characteristics Frame ranges Catalogue groups Illustration notes Newest parts Spec codes

Roof Headlining & Silencer Pad

8 part groups · 2 illustrations

Illustrations

Figure 64587TA 64587TA 2023-10 → — Figure 64587UA 64587UA 2023-10 → —

Part groups

PNCDescription
62401C Fastener, Hook
63310 Headlining Assy, Roof
63310H Clip(FOR ROOF HEADLINING)
63342 Pad, Roof Silencer, NO.2
63343 Pad, Roof Silencer, NO.3
63351B Pad, Roof Headlining
63387 Pad, Roof Headlining Forming
86255F Case, Microphone
PNC is the six-character part-group number the factory catalogue files parts under. Every part on a drawing belongs to one.
