Toyota C-hr (TUP)
2016-10 → present · chassis NGX10,50,ZYX10 · catalogue 528310 · General
Supported model
Data version 2019-09
Dashed callouts are standard fasteners the factory draws but does not list
as separate parts — there is no part number behind them.
| Part number | Description | Fitment | Price | |
|---|---|---|---|---|
| 11401G — Sensor, Crank Position | ||||
| 90919-05070 |
Sensor, Crank Position
2019-09 → —
|
2ZRFXE ZYX10 | — | |
| 11401V — O-ring, Crank Position Sensor | ||||
| 90301-14016 |
O-ring, Crank Position Sensor
2019-09 → —
|
2ZRFXE ZYX10 | — | |
| 11432A — Plug, W/Head Taper Screw, NO.1 | ||||
| 90345-53006 |
Plug, W/Head Taper Screw, NO.1
2019-09 → —
|
2ZRFXE ZYX10 | — | |
| 11434B — Pin, Straight(FOR CLUTCH HOUSING SET) | ||||
| 90250-10113 note |
Pin, Straight(FOR CLUTCH HOUSING SET)
2016-10 → 2019-09
ended
|
8NRFTS NGX10,50 | — | |
| 90250-10113 note |
Pin, Straight(FOR CLUTCH HOUSING SET)
2019-09 → —
|
2ZRFXE ZYX10 | — | |
| 90250-10113 note |
Pin, Straight(FOR CLUTCH HOUSING SET)
2019-09 → —
|
8NRFTS NGX10,50 | — | |
| 11434Y — Pin, Straight(FOR OIL PAN) | ||||
| 90250-08120 |
Pin, Straight(FOR OIL PAN)
2016-10 → 2019-09
ended
|
8NRFTS NGX10,50 | — | |
| 90250-08120 |
Pin, Straight(FOR OIL PAN)
2019-09 → —
|
2ZRFXE ZYX10 | — | |
| 90250-08120 |
Pin, Straight(FOR OIL PAN)
2019-09 → —
|
8NRFTS NGX10,50 | — | |
No quantity column: the factory catalogue records which parts a vehicle
takes, never how many.
