Toyota C-hr (TUP)
2016-10 → present · chassis NGX10,50,ZYX10 · catalogue 528310 · General
Supported model
Data version 2019-09
Dashed callouts are standard fasteners the factory draws but does not list
as separate parts — there is no part number behind them.
| Part number | Description | Fitment | Price | |
|---|---|---|---|---|
| 17650G — Valve, Duty Vacuum Switching | ||||
| 90910-12276 |
Valve, Duty Vacuum Switching
2019-09 → —
|
2ZRFXE ZYX10 | — | |
| 23818 — Pipe, Fuel Vapor Feed | ||||
| 23818-47020 |
Pipe, Fuel Vapor Feed
2016-10 → 2019-09
ended
|
8NRFTS NGX10,50 | — | |
| 23818-37030 |
Pipe, Fuel Vapor Feed
2019-09 → —
|
2ZRFXE ZYX10 | — | |
| 23818-47020 |
Pipe, Fuel Vapor Feed
2019-09 → —
|
8NRFTS NGX10,50 | — | |
| 23826 — Hose, Fuel Vapor Feed, NO.1 | ||||
| 23826-47090 |
Hose, Fuel Vapor Feed, NO.1
2016-10 → 2019-09
ended
|
8NRFTS NGX10,50 | — | |
| 23826-0T300 note |
Hose, Fuel Vapor Feed, NO.1
2019-09 → —
|
2ZRFXE ZYX10 | — | |
| 23826-37250 note |
Hose, Fuel Vapor Feed, NO.1
2019-09 → —
|
2ZRFXE ZYX10 | — | |
| 23826-47090 |
Hose, Fuel Vapor Feed, NO.1
2019-09 → —
|
8NRFTS NGX10,50 | — | |
| 23827A — Hose, Fuel Vapor Feed, NO.2 | ||||
| 23827-47130 |
Hose, Fuel Vapor Feed, NO.2
2016-10 → 2019-09
ended
|
8NRFTS NGX10,50 | — | |
| 23827-0T050 note |
Hose, Fuel Vapor Feed, NO.2
2019-09 → —
|
2ZRFXE ZYX10 | — | |
| 23827-37070 note |
Hose, Fuel Vapor Feed, NO.2
2019-09 → —
|
2ZRFXE ZYX10 | — | |
| 23827-47130 |
Hose, Fuel Vapor Feed, NO.2
2019-09 → —
|
8NRFTS NGX10,50 | — | |
| 23829A — Hose, Fuel Vapor Feed | ||||
| 23826-0Y080 |
Hose, Fuel Vapor Feed
2016-10 → 2017-12
ended
|
8NRFTS NGX10,50 | — | |
| 23826-0Y350 |
Hose, Fuel Vapor Feed
2017-12 → 2019-09
ended
|
8NRFTS NGX10,50 | — | |
| 23826-0T260 |
Hose, Fuel Vapor Feed
2019-09 → 2022-07
ended
|
2ZRFXE ZYX10 | — | |
| 23826-0T260 note |
Hose, Fuel Vapor Feed
2022-07 → —
|
2ZRFXE ZYX10 | — | |
| 23826-0Y350 |
Hose, Fuel Vapor Feed
2019-09 → 2022-07
ended
|
8NRFTS NGX10,50 | — | |
| 23826-0Y350 note |
Hose, Fuel Vapor Feed
2022-07 → —
|
8NRFTS NGX10,50 | — | |
| 23826-37241 note |
Hose, Fuel Vapor Feed
2022-07 → —
|
2ZRFXE ZYX10 | — | |
| 23826-47150 note |
Hose, Fuel Vapor Feed
2022-07 → —
|
8NRFTS NGX10,50 | — | |
| 23829B — Clip(FOR FUEL VAPOR FEED HOSE) | ||||
| 96136-41901 note |
Clip(FOR FUEL VAPOR FEED HOSE)
2016-10 → 2019-09
ended
|
8NRFTS NGX10,50 | — | |
| 96136-42201 note |
Clip(FOR FUEL VAPOR FEED HOSE)
2016-10 → 2019-09
ended
|
8NRFTS NGX10,50 | — | |
| 96136-41901 note |
Clip(FOR FUEL VAPOR FEED HOSE)
2019-09 → —
|
8NRFTS NGX10,50 | — | |
| 96136-41901 |
Clip(FOR FUEL VAPOR FEED HOSE)
2019-09 → —
|
2ZRFXE ZYX10 | — | |
| 96136-42201 note |
Clip(FOR FUEL VAPOR FEED HOSE)
2019-09 → —
|
8NRFTS NGX10,50 | — | |
No quantity column: the factory catalogue records which parts a vehicle
takes, never how many.
