Toyota C-hr (TUP)
2016-10 → present · chassis NGX10,50,ZYX10 · catalogue 528310 · General
Supported model
Data version 2019-09
Dashed callouts are standard fasteners the factory draws but does not list
as separate parts — there is no part number behind them.
| Part number | Description | Fitment | Price | |
|---|---|---|---|---|
| 27020 — Alternator Assy | ||||
| 27060-0Y210 note |
Alternator Assy
2016-10 → 2017-08
ended
|
8NRFTS NGX10,50 | — | |
| 27060-0Y211 note |
Alternator Assy
2017-09 → 2019-09
ended
|
8NRFTS NGX10,50 | — | |
| 27060-0Y211 note |
Alternator Assy
2019-09 → —
|
8NRFTS NGX10,50 | — | |
| 27039 — Cover, Alternator Rear End | ||||
| 27039-0Y210 |
Cover, Alternator Rear End
2016-10 → 2019-09
ended
|
8NRFTS NGX10,50 | — | |
| 27039-0Y210 |
Cover, Alternator Rear End
2019-09 → —
|
8NRFTS NGX10,50 | — | |
| 27403 — Pulley Set, Alternator | ||||
| 27403-0Y210 |
Pulley Set, Alternator
2016-10 → 2017-09
ended
|
8NRFTS NGX10,50 | — | |
| 27403-0Y211 |
Pulley Set, Alternator
2017-09 → 2019-09
ended
|
8NRFTS NGX10,50 | — | |
| 27403-0Y211 |
Pulley Set, Alternator
2019-09 → —
|
8NRFTS NGX10,50 | — | |
| 27702 — Regulator Sub-assy Generator W/Brush | ||||
| 27702-0Y090 |
Regulator Sub-assy Generator W/Brush
2016-10 → 2019-09
ended
|
8NRFTS NGX10,50 | — | |
| 27702-0Y090 |
Regulator Sub-assy Generator W/Brush
2019-09 → —
|
8NRFTS NGX10,50 | — | |
No quantity column: the factory catalogue records which parts a vehicle
takes, never how many.
