Toyota C-hr (TUP)

2016-10 → present · chassis NGX10,50,ZYX10 · catalogue 528310 · General

Supported model Data version 2019-09
Parts groups Model variants Characteristics Frame ranges Catalogue groups Illustration notes Newest parts Spec codes
Exploded illustration 761025G 7504 — not listed in this catalogue 65631D — PLATE, REAR WHEEL HOUSE, FRONT RH (2 parts) 65632D — PLATE, REAR WHEEL HOUSE, FRONT LH (2 parts) 76851A — COVER, FRONT SPOILER, RH (1 parts) 76852A — COVER, FRONT SPOILER, LH (1 parts) 76087A — SPOILER SUB-ASSY, REAR SIDE (2 parts) 76781A — TAPE, REAR SPOILER, UPPER NO.1 (2 parts) 76782A — TAPE, REAR SPOILER, UPPER NO.2 (2 parts) 76871 — SPOILER, REAR (5 parts) 76896 — PROTECTOR, REAR SPOILER, NO.6 (2 parts) 76896 — PROTECTOR, REAR SPOILER, NO.6 (2 parts) 76896 — PROTECTOR, REAR SPOILER, NO.6 (2 parts) 52161L — PIECE, FRONT SPOILER (1 parts) 76896 — PROTECTOR, REAR SPOILER, NO.6 (2 parts) 76872 — PROTECTOR, REAR SPOILER, NO.1 (3 parts) 76872 — PROTECTOR, REAR SPOILER, NO.1 (3 parts) 76873 — PROTECTOR, REAR SPOILER, NO.2 (2 parts) 76885 — RETAINER, REAR SPOILER, NO.5 (2 parts) 76887 — SEAL, REAR SPOILER (2 parts) 76891 — SPOILER, REAR NO.1 (5 parts) 76892 — SPOILER, REAR NO.2 (2 parts) 9011906993 — not listed in this catalogue 9015960477 — not listed in this catalogue 90178W0039 — not listed in this catalogue 9017906274 — not listed in this catalogue 9018305040 — not listed in this catalogue 9018906145 — not listed in this catalogue 9018906237 — not listed in this catalogue 9046709206 — not listed in this catalogue 9354013006 — not listed in this catalogue 9018305040 — not listed in this catalogue 9018305040 — not listed in this catalogue 9015950237 — not listed in this catalogue 9015950237 — not listed in this catalogue 9015960477 — not listed in this catalogue 7503 — not listed in this catalogue 8117 — not listed in this catalogue 8117 — not listed in this catalogue 8117 — not listed in this catalogue 76782A — TAPE, REAR SPOILER, UPPER NO.2 (2 parts) 76872 — PROTECTOR, REAR SPOILER, NO.1 (3 parts) 76872 — PROTECTOR, REAR SPOILER, NO.1 (3 parts) 76873 — PROTECTOR, REAR SPOILER, NO.2 (2 parts) 75392C — RETAINER, OUTSIDE MOULDING (1 parts)
761025G · 25 callouts, 19 unlisted Full size ↗
Dashed callouts are standard fasteners the factory draws but does not list as separate parts — there is no part number behind them.
37 parts on this figure
Part number Description Fitment Price
52161L — Piece, Front Spoiler
52161-02030 Piece, Front Spoiler
2019-09 → —
NGX10,50,ZYX10 —
65631D — Plate, Rear Wheel House, Front RH
65631-F4010 Plate, Rear Wheel House, Front RH
2016-10 → 2019-09 ended
NGX10,50 —
65631-F4010 Plate, Rear Wheel House, Front RH
2019-09 → —
NGX10,50,ZYX10 —
65632D — Plate, Rear Wheel House, Front LH
65632-F4010 Plate, Rear Wheel House, Front LH
2016-10 → 2019-09 ended
NGX10,50 —
65632-F4010 Plate, Rear Wheel House, Front LH
2019-09 → —
NGX10,50,ZYX10 —
75392C — Retainer, Outside Moulding
75392-35200 Retainer, Outside Moulding
2019-09 → —
NGX10,50,ZYX10 —
76087A — Spoiler Sub-assy, Rear Side
76895-F4010 Spoiler Sub-assy, Rear Side
2016-10 → 2019-09 ended
NGX10,50 —
76895-F4010 Spoiler Sub-assy, Rear Side
2019-09 → —
NGX10,50,ZYX10 —
76781A — Tape, Rear Spoiler, Upper NO.1
76781-F4010 note Tape, Rear Spoiler, Upper NO.1
2016-10 → 2019-09 ended
NGX10,50 —
76781-F4010 note Tape, Rear Spoiler, Upper NO.1
2019-09 → —
NGX10,50,ZYX10 —
76782A — Tape, Rear Spoiler, Upper NO.2
76782-F4010 note Tape, Rear Spoiler, Upper NO.2
2016-10 → 2019-09 ended
NGX10,50 —
76782-F4010 note Tape, Rear Spoiler, Upper NO.2
2019-09 → —
NGX10,50,ZYX10 —
76851A — Cover, Front Spoiler, RH
76851-F4010 Cover, Front Spoiler, RH
2019-09 → —
NGX10,50,ZYX10 —
76852A — Cover, Front Spoiler, LH
76852-F4010 Cover, Front Spoiler, LH
2019-09 → —
NGX10,50,ZYX10 —
76871 — Spoiler, Rear
76871-10150 note Spoiler, Rear
2017-11 → 2019-09 ended
NGX10,50 —
76871-F4900 note Spoiler, Rear
2016-10 → 2017-11 ended
NGX10,50 —
76871-F4900 note Spoiler, Rear
2017-11 → 2019-09 ended
NGX10,50 —
76871-10150 note Spoiler, Rear
2019-09 → —
NGX10,50,ZYX10 —
76871-F4900 note Spoiler, Rear
2019-09 → —
NGX10,50,ZYX10 —
76872 — Protector, Rear Spoiler, NO.1
76872-F4010 note Protector, Rear Spoiler, NO.1
2017-06 → 2019-09 ended
NGX10,50 —
76872-F4010 note Protector, Rear Spoiler, NO.1
2016-10 → 2017-06 ended
NGX10,50 —
76872-F4010 note Protector, Rear Spoiler, NO.1
2019-09 → —
NGX10,50,ZYX10 —
76873 — Protector, Rear Spoiler, NO.2
76873-F4010 note Protector, Rear Spoiler, NO.2
2016-10 → 2019-09 ended
NGX10,50 —
76873-F4010 note Protector, Rear Spoiler, NO.2
2019-09 → —
NGX10,50,ZYX10 —
76885 — Retainer, Rear Spoiler, NO.5
76885-F4010 Retainer, Rear Spoiler, NO.5
2016-10 → 2019-09 ended
NGX10,50 —
76885-F4010 Retainer, Rear Spoiler, NO.5
2019-09 → —
NGX10,50,ZYX10 —
76887 — Seal, Rear Spoiler
76887-F4010 Seal, Rear Spoiler
2016-10 → 2019-09 ended
NGX10,50 —
76887-F4010 Seal, Rear Spoiler
2019-09 → —
NGX10,50,ZYX10 —
76891 — Spoiler, Rear NO.1
76891-10020 note Spoiler, Rear NO.1
2017-11 → 2019-09 ended
NGX10,50 —
76891-F4010 Spoiler, Rear NO.1
2016-10 → 2017-11 ended
NGX10,50 —
76891-F4010 note Spoiler, Rear NO.1
2017-11 → 2019-09 ended
NGX10,50 —
76891-10020 note Spoiler, Rear NO.1
2019-09 → —
NGX10,50,ZYX10 —
76891-F4010 note Spoiler, Rear NO.1
2019-09 → —
NGX10,50,ZYX10 —
76892 — Spoiler, Rear NO.2
76892-F4010 Spoiler, Rear NO.2
2016-10 → 2019-09 ended
NGX10,50 —
76892-F4010 Spoiler, Rear NO.2
2019-09 → —
NGX10,50,ZYX10 —
76896 — Protector, Rear Spoiler, NO.6
76896-F4010 Protector, Rear Spoiler, NO.6
2016-10 → 2019-09 ended
NGX10,50 —
76896-F4010 Protector, Rear Spoiler, NO.6
2019-09 → —
NGX10,50,ZYX10 —
No quantity column: the factory catalogue records which parts a vehicle takes, never how many.
