Toyota C-hr (TUP)
2016-10 → present · chassis NGX10,50,ZYX10 · catalogue 528310 · General
Supported model
Data version 2019-09
Dashed callouts are standard fasteners the factory draws but does not list
as separate parts — there is no part number behind them.
| Part number | Description | Fitment | Price | |
|---|---|---|---|---|
| G9282 — Thermistor, Hybrid Battery | ||||
| G9282-47050 |
Thermistor, Hybrid Battery
2019-09 → —
|
ZYX10 | — | |
| G9289A — Label, Battery Caution | ||||
| G9288-02030 note |
Label, Battery Caution
2021-09 → —
|
ZYX10 | — | |
| G9288-48040 note |
Label, Battery Caution
2019-09 → 2021-09
ended
|
ZYX10 | — | |
| G9288-48040 note |
Label, Battery Caution
2021-09 → —
|
ZYX10 | — | |
| G9288-76030 |
Label, Battery Caution
2019-09 → —
|
ZYX10 | — | |
| G9298 — Clamp, HV Battery | ||||
| G928E-47010 |
Clamp, HV Battery
2019-09 → —
|
ZYX10 | — | |
| G92J5 — Packing, Hybrid Battery, NO.1 | ||||
| G92J5-47030 |
Packing, Hybrid Battery, NO.1
2019-09 → —
|
ZYX10 | — | |
| G9510 — Battery Assy, HV Supply | ||||
| G9510-47130 |
Battery Assy, HV Supply
2019-09 → —
|
ZYX10 | — | |
No quantity column: the factory catalogue records which parts a vehicle
takes, never how many.
