Toyota C-hr (TUP)
2016-10 → present · chassis NGX10,50,ZYX10 · catalogue 528310 · General
Supported model
Data version 2019-09
Dashed callouts are standard fasteners the factory draws but does not list
as separate parts — there is no part number behind them.
| Part number | Description | Fitment | Price | |
|---|---|---|---|---|
| 85910A — Relay Assy, Circuit Opening (FOR EFI) | ||||
| 90080-87021 |
Relay Assy, Circuit Opening (FOR EFI)
2019-09 → 2021-05
ended
|
ZYX10 | — | |
| 90987-02027 |
Relay Assy, Circuit Opening (FOR EFI)
2021-05 → —
|
ZYX10 | — | |
| 89421 — Sensor Assy, Vacuum (FOR E.F.I.) | ||||
| 89421-26030 |
Sensor Assy, Vacuum (FOR E.F.I.)
2019-09 → —
|
ZYX10 | — | |
| 89422 — Sensor, Water Temperature (FOR E.F.I.) | ||||
| 89422-33030 |
Sensor, Water Temperature (FOR E.F.I.)
2019-09 → —
|
ZYX10 | — | |
| 89661 — Computer, Engine Control | ||||
| 89661-F4080 note |
Computer, Engine Control
2016-10 → 2018-05
ended
|
NGX10 LHD 6F | — | |
| 89661-F4090 |
Computer, Engine Control
2016-10 → 2019-09
ended
|
NGX10 6F | — | |
| 89661-F4110 note |
Computer, Engine Control
2016-10 → 2019-09
ended
|
NGX10 LHD CVT | — | |
| 89661-F4120 |
Computer, Engine Control
2016-10 → 2019-09
ended
|
NGX10 CVT | — | |
| 89661-F4140 note |
Computer, Engine Control
2016-10 → 2018-05
ended
|
NGX50 LHD N | — | |
| 89661-F4140 note |
Computer, Engine Control
2016-10 → 2019-09
ended
|
NGX50 LHD E | — | |
| 89661-F4150 |
Computer, Engine Control
2016-10 → 2019-09
ended
|
NGX50 | — | |
| 89661-F4350 note |
Computer, Engine Control
2019-09 → —
|
ZYX10 | — | |
| 89661-F4420 note |
Computer, Engine Control
2019-09 → —
|
NGX10 6F | — | |
| 89661-F4450 note |
Computer, Engine Control
2019-09 → 2020-10
ended
|
NGX10 CVT | — | |
| 89661-F4480 note |
Computer, Engine Control
2019-09 → —
|
NGX50 | — | |
| 89661-F4580 note |
Computer, Engine Control
2020-10 → —
|
NGX10 CVT | — | |
| 89667E — Bracket, Engine Control Computer, NO.1 | ||||
| 89667-F4030 |
Bracket, Engine Control Computer, NO.1
2016-10 → 2019-09
ended
|
NGX10,50 | — | |
| 89667-02500 |
Bracket, Engine Control Computer, NO.1
2019-09 → —
|
ZYX10 | — | |
| 89667-F4030 |
Bracket, Engine Control Computer, NO.1
2019-09 → —
|
NGX10,50 | — | |
| 89668 — Bracket, Engine Control Computer, NO.2 | ||||
| 89668-02500 |
Bracket, Engine Control Computer, NO.2
2018-05 → 2019-09
ended
|
NGX10,50 | — | |
| 89668-F4030 |
Bracket, Engine Control Computer, NO.2
2016-10 → 2018-04
ended
|
NGX10,50 | — | |
| 89668-02500 |
Bracket, Engine Control Computer, NO.2
2019-09 → —
|
NGX10,50 | — | |
| 89668-F4020 |
Bracket, Engine Control Computer, NO.2
2019-09 → —
|
ZYX10 | — | |
No quantity column: the factory catalogue records which parts a vehicle
takes, never how many.
