Toyota Crown Kluger
2021-08 → present · chassis AXUH7#,SXUA75 · catalogue 52A310 · General
Supported model
Data version 2024-04
Rear Axle Housing & Differential
32 part groups · 2 illustrations
Part groups
| PNC | Description |
|---|---|
| 41108A | Plug (FOR REAR DIFFERENTIAL CARRIER COVER) |
| 41110 | Carrier Assy, Differential, Rear |
| 41110K | Plug, Breather (FOR REAR DIFFERENTIAL) |
| 41141E | Seal, Oil(FOR DIFFERENTIAL SIDE BEARING RETAINER) |
| 41173 | Cover, Differential Disconnect |
| 41181T | Plug (FOR REAR DIFFERENTIAL DRAIN) |
| 41181U | Gasket (FOR REAR DIFFERENTIAL DRAIN PLUG) |
| 41181V | Plug (FOR REAR DIFFERENTIAL FILLER) |
| 41181W | Gasket(FOR DIFFERENTIAL FILLER PLUG) |
| 41183 | Deflector, Rear Differential Breather Plug Oil |
| 41196 | Damper, Rear Differential Dynamic |
| 41196C | Damper, Rear Differential Dynamic, NO.2 |
| 41201B | Bearing (FOR REAR DRIVE PINION FRONT) |
| 41201C | Seal, Oil (FOR REAR DIFFERENTIAL CARRIER) |
| 41201D | Washer, Plate (FOR REAR DIFFERENTIAL DRIVE PINION) |
| 41204 | Flange Sub-assy, Rear Drive Pinion Companion, Rear |
| 41204B | Nut (FOR REAR DRIVE PINION) |
| 41231 | Spacer, Rear Differential Drive Pinion Bearing |
| 41231G | Spacer, Drive Pinion Bearing |
| 41252 | Deflector, Dust (FOR REAR DIFFERENTIAL) |
| 41252D | Deflector, Dust, NO.2 (FOR REAR DIFFERENTIAL) |
| 41303 | Coupling Sub-assy, Electro Magnetic Control |
| 41303F | Coupling Sub-assy, Electro Magnetic Control, LH |
| 41406A | Ring, O(FOR ELECTRO MAGNETIC CONTROL CLUTCH SUB-ASSY) |
| 41406B | Ring, O, NO.2(FOR ELECTRO MAGNETIC CONTROL CLUTCH SUB-ASSY) |
| 41651 | Cushion, Rear Differential Mount, NO.1 |
| 41653 | Stopper, Rear Differential Mount, Upper |
| 41653E | Stopper, Rear Differential Mount |
| 41654 | Stopper, Rear Differential Mount, Lower |
| 52380 | Support, Rear Differential, NO.1 |
| 52391A | Support, Rear Differential |
| 52391B | Support, Differential |
PNC is the six-character part-group number the factory catalogue files
parts under. Every part on a drawing belongs to one.
