Toyota Harrier/Hev (CHINA)
2021-11 → present · chassis AXUH8#,MXUA80 · catalogue 52B310 · General
Supported model
Data version 2023-03
Dashed callouts are standard fasteners the factory draws but does not list
as separate parts — there is no part number behind them.
| Part number | Description | Fitment | Price | |
|---|---|---|---|---|
| 82715W — Bracket, Wiring Harness Clamp | ||||
| 82715-07160 |
Bracket, Wiring Harness Clamp
2021-11 → 2023-04
ended
|
AXUH8# | — | |
| 8946A-0E030 |
Bracket, Wiring Harness Clamp
2023-04 → 2024-08
ended
|
AXUH85 M | — | |
| 8946A-0E030 |
Bracket, Wiring Harness Clamp
2023-04 → —
|
AXUH80;AXUH85 G,S | — | |
| 82715Y — Bracket, Wiring Harness Clamp, NO.3 | ||||
| 82715-0R810 |
Bracket, Wiring Harness Clamp, NO.3
2021-11 → 2023-04
ended
|
AXUH8#,MXUA80 | — | |
| 8946A-0R030 |
Bracket, Wiring Harness Clamp, NO.3
2023-04 → 2024-08
ended
|
AXUH85 M;MXUA80 S | — | |
| 8946A-0R030 |
Bracket, Wiring Harness Clamp, NO.3
2023-04 → —
|
AXUH85 G,S;AXUH80,MXUA80 G,M,X | — | |
| 89422A — Sensor, Water Temperature | ||||
| 89422-33040 |
Sensor, Water Temperature
2021-11 → 2024-08
ended
|
AXUH85 M;MXUA80 S | — | |
| 89422-33040 |
Sensor, Water Temperature
2021-11 → —
|
AXUH85 G,S;AXUH80,MXUA80 G,M,X | — | |
| 89425 — Sensor, Exhaust Gas Temperature | ||||
| 89425-0E030 |
Sensor, Exhaust Gas Temperature
2023-04 → 2024-08
ended
|
AXUH85 M;MXUA80 S | — | |
| 89425-0E030 |
Sensor, Exhaust Gas Temperature
2023-04 → —
|
AXUH85 G,S;AXUH80,MXUA80 G,M,X | — | |
| 89425A — Sensor, Exhaust Gas Temperature, NO.2 | ||||
| 89425-0E040 |
Sensor, Exhaust Gas Temperature, NO.2
2023-04 → 2024-08
ended
|
AXUH85 M | — | |
| 89425-0E040 |
Sensor, Exhaust Gas Temperature, NO.2
2023-04 → —
|
AXUH80;AXUH85 G,S | — | |
| 89425-0R010 |
Sensor, Exhaust Gas Temperature, NO.2
2023-04 → 2024-08
ended
|
MXUA80 S | — | |
| 89425-0R010 |
Sensor, Exhaust Gas Temperature, NO.2
2023-04 → —
|
MXUA80 G,M,X | — | |
| 89451A — Sensor, Shift Lever Position | ||||
| 89451-10010 |
Sensor, Shift Lever Position
2021-11 → 2024-08
ended
|
AXUH85 M | — | |
| 89451-10010 |
Sensor, Shift Lever Position
2021-11 → —
|
AXUH80;AXUH85 G,S | — | |
| 89467B — Sensor, Air Fuel Ratio | ||||
| 89467-0R110 |
Sensor, Air Fuel Ratio
2021-11 → 2023-04
ended
|
AXUH8# | — | |
| 89467-0R160 |
Sensor, Air Fuel Ratio
2023-04 → 2024-08
ended
|
MXUA80 S | — | |
| 89467-0R160 |
Sensor, Air Fuel Ratio
2023-04 → —
|
MXUA80 G,M,X | — | |
| 89467-0R190 |
Sensor, Air Fuel Ratio
2023-04 → —
|
AXUH80;AXUH85 G,S | — | |
| 89467-0R190 |
Sensor, Air Fuel Ratio
2023-04 → 2024-08
ended
|
AXUH85 M | — | |
| 89467-F4010 |
Sensor, Air Fuel Ratio
2021-11 → 2023-04
ended
|
MXUA80 | — | |
| 89467C — Sensor, Air Fuel Ratio, NO.2 | ||||
| 89467-0R120 |
Sensor, Air Fuel Ratio, NO.2
2021-11 → 2023-04
ended
|
AXUH8#,MXUA80 | — | |
| 89467-0R170 |
Sensor, Air Fuel Ratio, NO.2
2023-04 → 2024-08
ended
|
AXUH85 M;MXUA80 S | — | |
| 89467-0R170 |
Sensor, Air Fuel Ratio, NO.2
2023-04 → —
|
AXUH85 G,S;AXUH80,MXUA80 G,M,X | — | |
| 89481B — Sensor, Differential Pressure | ||||
| 89481-0E010 note |
Sensor, Differential Pressure
2023-04 → 2024-08
ended
|
MXUA80 S | — | |
| 89481-0E010 note |
Sensor, Differential Pressure
2023-04 → —
|
MXUA80 G,M,X | — | |
| 89481-48010 note |
Sensor, Differential Pressure
2023-04 → —
|
MXUA80 G,M,X | — | |
| 89481-48010 note |
Sensor, Differential Pressure
2023-04 → 2024-08
ended
|
MXUA80 S | — | |
| 89481-K0010 |
Sensor, Differential Pressure
2023-04 → 2024-08
ended
|
AXUH85 M | — | |
| 89481-K0010 |
Sensor, Differential Pressure
2023-04 → —
|
AXUH80;AXUH85 G,S | — | |
| 89491 — Sensor, Engine Oil Level | ||||
| 89491-06010 |
Sensor, Engine Oil Level
2021-11 → 2022-01
ended
|
AXUH8# | — | |
| 89491-06010 |
Sensor, Engine Oil Level
2021-11 → 2022-05
ended
|
MXUA80 | — | |
| 89491-06011 |
Sensor, Engine Oil Level
2022-06 → 2023-04
ended
|
MXUA80 | — | |
| 89491-06011 |
Sensor, Engine Oil Level
2022-02 → 2024-08
ended
|
AXUH85 M | — | |
| 89491-06011 |
Sensor, Engine Oil Level
2022-02 → —
|
AXUH80;AXUH85 G,S | — | |
| 89615 — Sensor, Knock Control | ||||
| 89615-0E010 |
Sensor, Knock Control
2021-11 → 2024-08
ended
|
AXUH85 M;MXUA80 S | — | |
| 89615-0E010 |
Sensor, Knock Control
2021-11 → —
|
AXUH85 G,S;AXUH80,MXUA80 G,M,X | — | |
No quantity column: the factory catalogue records which parts a vehicle
takes, never how many.
