Toyota Venza
2022-03 → present · chassis AXUH8#,MXUA8# · catalogue 52C310 · General
Supported model
Data version 2022-02
Dashed callouts are standard fasteners the factory draws but does not list
as separate parts — there is no part number behind them.
| Part number | Description | Fitment | Price | |
|---|---|---|---|---|
| 30400A — Bolt(FOR TRANSAXLE & ENGINE SETTING) | ||||
| 90105-C0259 |
Bolt(FOR TRANSAXLE & ENGINE SETTING)
2022-03 → 2023-03
ended
|
MXUA8# | — | |
| 90105-C0259 note |
Bolt(FOR TRANSAXLE & ENGINE SETTING)
2023-03 → —
|
MXUA8# | — | |
| 91552-81250 note |
Bolt(FOR TRANSAXLE & ENGINE SETTING)
2023-03 → —
|
MXUA8# | — | |
| 30400E — Seal, Type T Oil(FOR CVT OIL PUMP) | ||||
| 90311-41019 |
Seal, Type T Oil(FOR CVT OIL PUMP)
2022-03 → —
|
MXUA8# | — | |
| 35105C — Bolt(FOR TRANSAXLE HOUSING & CASE SET) | ||||
| 91551-00830 |
Bolt(FOR TRANSAXLE HOUSING & CASE SET)
2022-03 → —
|
MXUA8# | — | |
| 35482C — Clamp, Temperature Sensor | ||||
| 35482-73010 |
Clamp, Temperature Sensor
2022-03 → —
|
MXUA8# | — | |
No quantity column: the factory catalogue records which parts a vehicle
takes, never how many.
