Toyota Izoa
2020-05 → 2022-07 · chassis KPX10 · catalogue 539310 · General
Supported model
Data version 2023-05
| Part number | Description | Fitment | Price | |
|---|---|---|---|---|
| 04423 — Fitting Kit, Tire Pressure Monitor OR Balancer Valve | ||||
| 04423-0N010 |
Fitting Kit, Tire Pressure Monitor OR Balancer Valve
2020-05 → —
|
KPX10 | — | |
| 42601 — Wheel, Disc | ||||
| 42611-F4160 note |
Wheel, Disc
2020-05 → —
|
KPX10 | — | |
| 42601A — Wheel, Disc (FOR SPARE) | ||||
| 42611-0N111 note |
Wheel, Disc (FOR SPARE)
2020-05 → —
|
KPX10 | — | |
| 42601C — Nut, Hub (FOR AXLE) | ||||
| 90942-01033 note |
Nut, Hub (FOR AXLE)
2020-05 → —
|
KPX10 | — | |
| 90942-C1001 note |
Nut, Hub (FOR AXLE)
2020-05 → —
|
KPX10 | — | |
| 42603 — Ornament Sub-assy, Wheel Hub | ||||
| 42603-02320 note |
Ornament Sub-assy, Wheel Hub
2020-05 → —
|
KPX10 | — | |
| 42607 — Valve Sub-assy, Tire Pressure Monitor | ||||
| 42607-02090 |
Valve Sub-assy, Tire Pressure Monitor
2020-05 → —
|
KPX10 | — | |
| 42607D — Valve, Tire Pressure Monitor | ||||
| 90942-C5003 |
Valve, Tire Pressure Monitor
2020-05 → —
|
KPX10 | — | |
| 42611J — Valve (FOR TUBELESS TIRE SPARE) | ||||
| 90942-05009 note |
Valve (FOR TUBELESS TIRE SPARE)
2020-05 → —
|
KPX10 | — | |
| 42611U — Cap, Tire Valve | ||||
| 90942-C5001 |
Cap, Tire Valve
2020-05 → —
|
KPX10 | — | |
| 42621C — Cap, Wheel, W/Valve Hole | ||||
| 42602-F4060 |
Cap, Wheel, W/Valve Hole
2020-05 → —
|
KPX10 | — | |
| 42621D — Cap, Wheel, W/O Valve Hole | ||||
| 42602-F4040 |
Cap, Wheel, W/O Valve Hole
2020-05 → —
|
KPX10 | — | |
No quantity column: the factory catalogue records which parts a vehicle
takes, never how many.
