Toyota Izoa
2020-05 → 2022-07 · chassis KPX10 · catalogue 539310 · General
Supported model
Data version 2023-05
| Part number | Description | Fitment | Price | |
|---|---|---|---|---|
| 63306 — Trim Sub-assy, Sunshade | ||||
| 63306-F4010-C1 note |
Trim Sub-assy, Sunshade
2020-05 → 2022-08
ended
|
KPX10 E | — | |
| 63306-F4010-C1 note |
Trim Sub-assy, Sunshade
2020-05 → —
|
KPX10 N | — | |
| 63306-F4010-C1 note |
Trim Sub-assy, Sunshade
2020-05 → —
|
KPX10 E | — | |
| 63306-F4010-C1 note |
Trim Sub-assy, Sunshade
2020-05 → 2022-08
ended
|
KPX10 N | — | |
| 63310 — Headlining Assy, Roof | ||||
| 63310-F4010-C1 note |
Headlining Assy, Roof
2020-05 → 2020-12
ended
|
KPX10 D | — | |
| 63310-F4010-C1 note |
Headlining Assy, Roof
2020-05 → 2020-12
ended
|
KPX10 N | — | |
| 63310-F4010-C1 note |
Headlining Assy, Roof
2020-05 → 2020-12
ended
|
KPX10 E | — | |
| 63310-F4011-C1 note |
Headlining Assy, Roof
2021-01 → —
|
KPX10 N | — | |
| 63310-F4011-C1 note |
Headlining Assy, Roof
2021-01 → —
|
KPX10 E | — | |
| 63310-F4011-C1 note |
Headlining Assy, Roof
2021-01 → —
|
KPX10 D | — | |
| 63310-F4021-C1 note |
Headlining Assy, Roof
2020-05 → 2020-12
ended
|
KPX10 E | — | |
| 63310-F4021-C1 note |
Headlining Assy, Roof
2020-05 → 2020-12
ended
|
KPX10 N | — | |
| 63310-F4022-C1 note |
Headlining Assy, Roof
2021-01 → —
|
KPX10 N | — | |
| 63310-F4022-C1 note |
Headlining Assy, Roof
2021-01 → —
|
KPX10 E | — | |
| 63310H — Clip(FOR ROOF HEADLINING) | ||||
| 90467-07215 |
Clip(FOR ROOF HEADLINING)
2020-05 → —
|
KPX10 | — | |
| 63323E — Case, Headlining Lamp | ||||
| 63323-F4030 |
Case, Headlining Lamp
2020-05 → —
|
KPX10 D | — | |
| 63323-F4030 note |
Case, Headlining Lamp
2020-05 → —
|
KPX10 E,N | — | |
| 63323-F4050 |
Case, Headlining Lamp
2020-05 → —
|
KPX10 E,N | — | |
| 63367B — Plate, Roof Headlining Set, NO.2 RH | ||||
| 63367-F4011 |
Plate, Roof Headlining Set, NO.2 RH
2020-05 → —
|
KPX10 E,N | — | |
| 63368B — Plate, Roof Headlining Set, NO.2 LH | ||||
| 63368-F4011 |
Plate, Roof Headlining Set, NO.2 LH
2020-05 → —
|
KPX10 E,N | — | |
No quantity column: the factory catalogue records which parts a vehicle
takes, never how many.
