Toyota Izoa
2020-05 → 2022-07 · chassis KPX10 · catalogue 539310 · General
Supported model
Data version 2023-05
| Part number | Description | Fitment | Price | |
|---|---|---|---|---|
| 11285A — Label, Coolant System Notice | ||||
| 11285-11020 |
Label, Coolant System Notice
2020-05 → —
|
4KM KPX10 | — | |
| 16793E — Label, Cooling Fan Caution | ||||
| 16793-36030 |
Label, Cooling Fan Caution
2020-05 → —
|
4KM KPX10 | — | |
| 47997C — Label, Accumulator Caution, NO.1 | ||||
| 47997-76010 |
Label, Accumulator Caution, NO.1
2020-05 → —
|
KPX10 | — | |
| 74515A — Plate, Theft Warning | ||||
| 74515-06020 |
Plate, Theft Warning
2020-05 → 2020-07
ended
|
KPX10 | — | |
| 74573D — Label, Electric Vehicle Battery Caution | ||||
| 74573-F4010 |
Label, Electric Vehicle Battery Caution
2020-05 → —
|
KPX10 | — | |
| 74573E — Label, Electric Vehicle Battery Caution, NO.2 | ||||
| 74573-F4030 |
Label, Electric Vehicle Battery Caution, NO.2
2020-05 → —
|
KPX10 | — | |
| 74751 — Label, Tire Pressure Information | ||||
| 42661-F4180 note |
Label, Tire Pressure Information
2020-05 → —
|
KPX10 | — | |
| 42661-F4200 |
Label, Tire Pressure Information
2020-05 → —
|
KPX10 | — | |
| 88723H — Label, Cooler Service Caution | ||||
| 88723-F4090 |
Label, Cooler Service Caution
2020-05 → —
|
KPX10 | — | |
| G9275 — Label, Battery Caution, NO.1 | ||||
| G9275-F4010 |
Label, Battery Caution, NO.1
2020-05 → —
|
KPX10 | — | |
| G92A1 — Label, Hybrid Coolant System Information | ||||
| G92A1-76010 |
Label, Hybrid Coolant System Information
2020-05 → —
|
KPX10 | — | |
No quantity column: the factory catalogue records which parts a vehicle
takes, never how many.
