Toyota Izoa
2020-05 → 2022-07 · chassis KPX10 · catalogue 539310 · General
Supported model
Data version 2023-05
Dashed callouts are standard fasteners the factory draws but does not list
as separate parts — there is no part number behind them.
| Part number | Description | Fitment | Price | |
|---|---|---|---|---|
| 75533 — Moulding, Windshield, Outside RH | ||||
| 75535-F4030 |
Moulding, Windshield, Outside RH
2020-05 → —
|
KPX10 | — | |
| 75534 — Moulding, Windshield, Outside LH | ||||
| 75536-F4030 |
Moulding, Windshield, Outside LH
2020-05 → —
|
KPX10 | — | |
| 75545B — Clip, Windshield Outside Moulding, NO.1 | ||||
| 75545-F4030 |
Clip, Windshield Outside Moulding, NO.1
2020-05 → —
|
KPX10 | — | |
| 75547C — Clip, Windshield Outside Moulding, NO.3 | ||||
| 75547-0N010 |
Clip, Windshield Outside Moulding, NO.3
2020-05 → —
|
KPX10 | — | |
No quantity column: the factory catalogue records which parts a vehicle
takes, never how many.
