Toyota Izoa
2020-05 → 2022-07 · chassis KPX10 · catalogue 539310 · General
Supported model
Data version 2023-05
Dashed callouts are standard fasteners the factory draws but does not list
as separate parts — there is no part number behind them.
| Part number | Description | Fitment | Price | |
|---|---|---|---|---|
| G9060D — Cover, EV Charger Cable | ||||
| 82821-F4040 |
Cover, EV Charger Cable
2020-05 → —
|
KPX10 | — | |
| G9060F — Cable Assy, Electric Vehicle Charger | ||||
| G9060-F4010 |
Cable Assy, Electric Vehicle Charger
2020-05 → —
|
KPX10 | — | |
| G90G0A — Plug Assy, Cable EV Charger | ||||
| G90G0-12010 |
Plug Assy, Cable EV Charger
2020-05 → —
|
KPX10 | — | |
| G926KA — Key, Plug Cable EV Charger | ||||
| G926K-47020 |
Key, Plug Cable EV Charger
2020-05 → —
|
KPX10 | — | |
| G926LA — Cover, Plug Cable EV Charger | ||||
| G926L-47020 |
Cover, Plug Cable EV Charger
2020-05 → —
|
KPX10 | — | |
No quantity column: the factory catalogue records which parts a vehicle
takes, never how many.
