Toyota Izoa
2020-05 → 2022-07 · chassis KPX10 · catalogue 539310 · General
Supported model
Data version 2023-05
Dashed callouts are standard fasteners the factory draws but does not list
as separate parts — there is no part number behind them.
| Part number | Description | Fitment | Price | |
|---|---|---|---|---|
| 86401 — Hood Sub-assy, Forward Recognition W/Heater | ||||
| 86401-10010 |
Hood Sub-assy, Forward Recognition W/Heater
2020-05 → 2021-04
ended
|
KPX10 | — | |
| 86401-F4040 |
Hood Sub-assy, Forward Recognition W/Heater
2021-04 → —
|
KPX10 | — | |
| 86464A — Latch, Forward Recognition | ||||
| 86464-F4040 |
Latch, Forward Recognition
2021-04 → —
|
KPX10 | — | |
| 86464-K0010 |
Latch, Forward Recognition
2020-05 → 2021-03
ended
|
KPX10 | — | |
| 86466D — Cover, Forward Recognition, NO.1 | ||||
| 86466-10030 |
Cover, Forward Recognition, NO.1
2020-05 → 2021-03
ended
|
KPX10 | — | |
| 86466-F4080 |
Cover, Forward Recognition, NO.1
2021-04 → —
|
KPX10 | — | |
| 86466E — Cover, Forward Recognition, NO.2 | ||||
| 86466-10040 |
Cover, Forward Recognition, NO.2
2020-05 → 2021-03
ended
|
KPX10 | — | |
| 86467-F4020 |
Cover, Forward Recognition, NO.2
2021-04 → —
|
KPX10 | — | |
| 8646C — Camera, Forward Recognition | ||||
| 8646C-F4060 |
Camera, Forward Recognition
2020-05 → 2020-11
ended
|
KPX10 | — | |
| 8646C-F4090 |
Camera, Forward Recognition
2020-12 → —
|
KPX10 | — | |
No quantity column: the factory catalogue records which parts a vehicle
takes, never how many.
