Toyota Qualis

1999-12 → 2004-12 · chassis LF50,RZF50 · catalogue 611250 · General

Discontinued model Data version 2005-07
Parts groups Model variants Characteristics Frame ranges Catalogue groups Illustration notes Newest parts Spec codes

Front Fender Apron & Dash Panel

22 part groups · 2 illustrations

Illustrations

Figure 530882A 530882A 1999-12 → 2002-09 Figure 531356E 531356E 2002-09 → —

Part groups

PNCDescription
53201 Support Sub-assy, Radiator
53202 Support Sub-assy, Radiator, RH
53203 Support Sub-assy, Radiator, LH
53205 Support Sub-assy, Radiator, Upper
53209B Brace Sub-assy, Hood Lock Support
53218A Support, Radiator, Lower
53219A Support, Radiator, Lower Rear
53221B Brace, Radiator Support Apron, RH
53222B Brace, Radiator Support Apron, LH
53223C Bracket, Radiator Grille Mounting, RH
53224B Bracket, Radiator Grille Mounting, LH
53701 Apron Sub-assy, Front Fender, RH
53702 Apron Sub-assy, Front Fender, LH
53714G Plate, Fender Apron Splash, LH
53738D Seal, Front Fender Apron TO Frame, Front
53739C Seal, Front Fender Apron TO Frame, Rear
53886H Shield, Front Fender Splash, Rear LH
53891H Seal, Front Fender Splash Shield, Front RH
53896E Shield, Front Fender Splash, Front LH
55101 Panel Sub-assy, Dash
55210 Insulator Assy, Dash Panel
55220 Insulator Assy, Dash Panel, NO.2
PNC is the six-character part-group number the factory catalogue files parts under. Every part on a drawing belongs to one.
