Toyota Innova/Kijang Innova
2011-07 → 2016-11 · chassis KUN40,TGN4# · catalogue 611270 · General
Supported model
Data version 2017-05
Air Cleaner
40 part groups · 4 illustrations
Part groups
| PNC | Description |
|---|---|
| 12268B | Hose, Oil Return |
| 12268C | Clip, Hose |
| 17080 | Cleaner Assy, Air W/Air Flow Meter |
| 17138 | Stay, Intake Pipe OR Hose |
| 17341F | Hose, Air, NO.1 |
| 17341G | Clamp OR Clip(FOR AIR HOSE, NO.1) |
| 17341K | Hose, Air, NO.1(FOR INTERCOOLER) |
| 17341L | Clamp, Hose |
| 17342D | Hose, Air, NO.2 |
| 17342F | Hose, Air, NO.2(FOR INTERCOOLER) |
| 17342G | Clamp, Hose, NO.2(FOR INTERCOOLER) |
| 17343D | Hose, Air, NO.3 |
| 17343E | Clamp, Hose(FOR AIR HOSE, NO.3) |
| 17344E | Hose, Air, NO.4 |
| 17344F | Clamp, Hose(FOR AIR HOSE, NO.4) |
| 17361J | Tube, Air, NO.1 |
| 17362B | Tube, Air, NO.2 |
| 17362E | Clamp, NO.2(FOR AIR TUBE, NO.2) |
| 17363K | Tube, Air, NO.3(FOR INTERCOOLER) |
| 17700 | Cleaner Assy, Air |
| 17701 | Case Sub-assy, Air Cleaner |
| 17705 | Cap Sub-assy, Air Cleaner |
| 17750 | Cover Assy, Air Cleaner Inlet, Seal |
| 17801 | Element Sub-assy, Air Cleaner Filter |
| 17806 | Pipe Sub-assy, Air Cleaner, NO.2 |
| 17861 | Connector, Intake Air |
| 17861D | Clamp(FOR INTAKE AIR CONNECTOR) |
| 17878 | Pipe, Intake Air Connector, NO.3 |
| 17880 | Hose Assy, Air Cleaner |
| 17881 | Hose, Air Cleaner, NO.1 |
| 17881A | Clamp(FOR AIR CLEANER HOSE, NO.1) |
| 17882B | Clamp(FOR COOL AIR INTAKE) |
| 17883 | Hose, Air Cleaner, NO.3 |
| 17893 | Resonator, Intake Air |
| 17893A | Clamp, Hose |
| 17909 | Duct Sub-assy, Intercooler Cooling Air |
| 17940D | Intercooler Assy |
| 17947B | Bracket, Intercooler Support, NO.3 |
| 22204 | Meter Sub-assy, Intake Air Flow |
| 22204A | Ring, O(FOR INTAKE AIR FLOW METER) |
PNC is the six-character part-group number the factory catalogue files
parts under. Every part on a drawing belongs to one.
