Toyota Innova
2015-11 → present · chassis GUN14#,TGN14# · catalogue 611280 · General
Supported model
Data version 2021-11
Instrument Panel & Glove Compartment
47 part groups · 8 illustrations
Part groups
| PNC | Description |
|---|---|
| 52161V | Piece, Instrument Panel |
| 55054 | Stopper Sub-assy, Glove Compartment Door |
| 55302A | Panel Sub-assy, Instrument, Upper |
| 55303B | Panel Sub-assy, Instrument, Lower |
| 55306A | Brace Sub-assy, Instrument Panel, NO.1 |
| 55307C | Brace Sub-assy, Instrument Panel, NO.2 |
| 55312A | Clip, Instrument Panel |
| 55317A | Panel, Instrument Side, RH |
| 55318C | Panel, Instrument Side, LH |
| 55326B | Stay, Instrument Panel, RH |
| 55327B | Stay, Instrument Panel, LH |
| 55330B | Reinforcement Assy, Instrument Panel |
| 55330C | Plug, Hole(FOR INSTRUMENT PANEL) |
| 55355 | Cushion, Instrument Panel, NO.1 |
| 55356C | Cushion, Instrument Panel, NO.2 |
| 55395C | Cover, Instrument Panel Bracket, Inner NO.1 LH |
| 55410C | Panel Assy, Instrument Cluster Finish |
| 55412D | Panel, Instrument Cluster Finish, Center |
| 55421B | Panel, Instrument Cluster Finish, Upper |
| 55431B | Panel, Instrument Panel Finish, Upper |
| 55434B | Panel, Instrument Panel Finish, Lower Center |
| 55440C | Box Assy, Instrument Panel |
| 55446A | Base, Switch Hole, NO.1 |
| 55471A | Ornament, Instrument Cluster Finish Panel |
| 55474C | Garnish, Instrument Cluster Finish Panel, NO.1 |
| 55475A | Garnish, Instrument Cluster Finish Panel, NO.2 |
| 55480D | Panel Assy, Instrument Panel Finish, Lwr |
| 55522B | Cover, Radio Tuner Opening |
| 55531C | Pin, Glove Door Stopper |
| 55539 | Cover, Spare Switch Hole |
| 55539B | Cover, Spare Switch Hole, NO.2 |
| 55549B | Cover, Instrument Panel Hole, NO.2 |
| 55550 | Door Assy, Glove Compartment |
| 55557A | Cushion, Glove Compartment Door Check |
| 55557B | Stopper, Glove Compertment Door Check |
| 55606 | Cover Sub-assy, Instrument Panel Under, NO.1 |
| 55618C | Holder, Instrument Panel Cup |
| 55619H | Holder, Instrument Panel Cup, NO.2 |
| 55623A | Spring, Instrument Panel Cup Holder, NO.2 |
| 55623B | Spring, Instrument Panel Cup Holder |
| 55650 | Register Assy, Instrument Panel, NO.1 |
| 55660 | Register Assy, Instrument Panel, NO.2 |
| 55670 | Register Assy, Instrument Panel, NO.3 |
| 55680A | Register Assy, Instrument Panel, NO.4 |
| 61181 | Bracket, Instrument Panel Side |
| 73900 | Airbag Assy, Instrument Panel, Lower NO.1 |
| 73960A | Airbag Assy, Instrument Panel Passenger W/O Door |
PNC is the six-character part-group number the factory catalogue files
parts under. Every part on a drawing belongs to one.
