Toyota Innova
2015-11 → present · chassis GUN14#,TGN14# · catalogue 611280 · General
Supported model
Data version 2021-11
Seat Belt
35 part groups · 4 illustrations
Part groups
| PNC | Description |
|---|---|
| 73023 | Plate Sub-assy, Front Shoulder Belt Anchor, RH |
| 73024 | Plate Sub-assy, Front Shoulder Belt Anchor, LH |
| 73119 | Plate, Seat Belt Webbing Clip |
| 73139B | Cover, Seat Belt Anchor |
| 73139C | Cover, Rear Seat Belt |
| 73200A | Adjuster Assy, Front Shoulder Belt Anchor |
| 73210 | Belt Assy, Front Seat Outer, RH |
| 73214 | Plate, Front Seat Belt Anchor |
| 73219 | Stopper, Tongue Plate |
| 73220 | Belt Assy, Front Seat Outer, LH |
| 73230 | Belt Assy, Front Seat Inner, RH |
| 73233 | Cover, Lap Belt Outer Anchor |
| 73233A | Cover, Lap Belt Outer Anchor, Rear NO.1 Seat |
| 73240 | Belt Assy, Front Seat Inner, LH |
| 73320A | Belt Assy, NO.1 Seat 3 Point Type, LH |
| 73330D | Belt Assy, Rear NO.1 Seat Lap Type, Center RH |
| 73350A | Belt Assy, Rear NO.1 Seat Lap Type, Center |
| 73360C | Belt Assy, Rear NO.1 Seat, Outer RH |
| 73370C | Belt Assy, Rear NO.1 Seat, Outer LH |
| 73371A | Hanger Rear Seat Shoulder Belt |
| 73371C | Hanger, Rear NO.2 Seat Shoulder Belt, RH |
| 73372C | Hanger, Rear NO.2 Seat Shoulder Belt, LH |
| 73375A | Clip, Rear Seat Belt Cover |
| 73380C | Belt Assy, Rear NO.1 Seat, Inner RH |
| 73381 | Holder, Rear Seat Belt |
| 73381A | Holder, Rear Seat Belt NO.2 |
| 73381C | Holder, Seat Belt |
| 73390C | Belt Assy, Rear NO.1 Seat, Inner LH |
| 73510A | Belt Assy, Rear NO.2 Seat, 3 Point Type |
| 73530A | Belt Assy, Rear NO.2 Seat Lap Type, RH |
| 73540A | Belt Assy, Rear NO.2 Seat Lap Type, LH |
| 73560 | Belt Assy, Rear NO.2 Seat, Outer RH |
| 73570 | Belt Assy, Rear NO.2 Seat, Outer LH |
| 73580 | Belt Assy, Rear NO.2 Seat, Inner RH |
| 73590 | Belt Assy, Rear NO.2 Seat, Inner LH |
PNC is the six-character part-group number the factory catalogue files
parts under. Every part on a drawing belongs to one.
