Toyota Innova

2015-11 → present · chassis GUN14#,TGN14# · catalogue 611280 · General

Supported model Data version 2021-11
Parts groups Model variants Characteristics Frame ranges Catalogue groups Illustration notes Newest parts Spec codes

Air Bag

7 part groups · 12 illustrations

Illustrations

Figure 84G793C 84G793C 2015-11 → 2020-08 Figure 84G793C 84G793C 2015-11 → 2020-08 Figure 84G793C 84G793C 2015-11 → 2020-09 Figure 84G793C 84G793C 2015-11 → 2020-10 Figure 84G793C 84G793C 2015-11 → — Figure 84G793C 84G793C 2015-11 → — Figure 84G793C 84G793C 2015-11 → — Figure 84G793C 84G793C 2020-01 → 2020-09 Figure 84M233A 84M233A 2020-09 → 2020-12 Figure 84M233A 84M233A 2020-09 → 2020-12 Figure 84M777A 84M777A 2020-12 → — Figure 84M777A 84M777A 2020-12 → —

Part groups

PNCDescription
89170A Computer Assy, Airbag
89173A Sensor, Airbag, Front RH
89174A Sensor, Airbag, Front LH
89835 Sensor, Door Side Airbag, LH
89860 Sensor Assy, Side Airbag, RH
89860A Sensor Assy, Side Airbag, LH
89865 Sensor, Door Side Airbag, RH
PNC is the six-character part-group number the factory catalogue files parts under. Every part on a drawing belongs to one.
