Toyota Innova
2022-11 → present · chassis MAGA10,MAGH10 · catalogue 614210 · General
Supported model
Data version 2024-03
Floor Mat & Silencer Pad
15 part groups · 6 illustrations
Part groups
| PNC | Description |
|---|---|
| 58410R | Board Assy, Deck |
| 58441J | Cover, Battery Service Hole |
| 58510D | Carpet Assy, Floor, Front |
| 58521F | Hook, Floor Carpet |
| 58523E | Bracket, Floor Carpet Set |
| 58530B | Clip(FOR FRONT FLOOR CARPET) |
| 58540F | Clip(FOR REAR FLOOR CARPET) |
| 58569D | Cover, Front Floor Caution Plate |
| 58569H | Clip, Front Floor Caution Plate Cover, NO.1 |
| 58570C | Carpet Assy, Rear Floor |
| 58694A | Plate, Mat Set, Upper |
| 58698B | Plate, Mat Set, Lower |
| 64993C | Box, Deck Floor, Rear |
| 67913A | Clip(FOR SCUFF PLATE) |
| 67935 | Plate, Back Door Scuff |
PNC is the six-character part-group number the factory catalogue files
parts under. Every part on a drawing belongs to one.
