Toyota Rush

2017-12 → present · chassis F800 · catalogue 615320 · General

Supported model Data version 2019-07
Parts groups Model variants Characteristics Frame ranges Catalogue groups Illustration notes Newest parts Spec codes

Cowl Panel & Windshield Glass

20 part groups · 2 illustrations

Illustrations

Figure 554099A 554099A 2017-12 → — Figure 554098A 554098A 2018-04 → —

Part groups

PNCDescription
53383 Seal, Hood TO Cowl Top
55703A Panel Sub-assy, Cowl Top, Inner
55711 Panel, Cowl Top, Outer
55713A Panel, Cowl Top Side, RH
55714A Panel, Cowl Top Side, LH
55718D Bracket, Cowl Top Outer Panel, NO.1
55721A Brace, Cowl Top TO Cowl, Inner NO.1
55723C Reinforcement, Cowl Top Side, RH
55724A Reinforcement, Cowl Top Side, LH
55737C Bracket, Cowl Top Outer Panel, NO.3
55781E Louver Sub-assy, Cowl Top Ventilator
55781F Louver, Cowl Top Ventilator
55781G Clip, Cowl Top Ventilator Louver
56111 Glass, Windshield
56115C Stopper, Windshield Glass
56116C Stopper, Windshield Glass, NO.2
56117A Dam, Window Glass Adhesive
56118B Dam, Window Glass Adhesive, NO.2
61121C Panel, Cowl Side, Outer RH
61122C Panel, Cowl Side, Outer LH
PNC is the six-character part-group number the factory catalogue files parts under. Every part on a drawing belongs to one.
