Toyota Rush
2018-12 → 2023-10 · chassis F850 · catalogue 617310 · General
Supported model
Data version 2018-11
Dashed callouts are standard fasteners the factory draws but does not list
as separate parts — there is no part number behind them.
| Part number | Description | Fitment | Price | |
|---|---|---|---|---|
| 16100 — Pump Assy, Engine Water | ||||
| 16100-B9490 |
Pump Assy, Engine Water
2018-12 → 2023-10
ended
|
2NRVE F850 | — | |
| 16271 — Gasket, Water Pump | ||||
| 16271-0Y030 |
Gasket, Water Pump
2018-12 → 2023-10
ended
|
2NRVE F850 | — | |
| 16603 — Pulley Sub-assy, Idler, NO.1 | ||||
| 16603-BZ041 |
Pulley Sub-assy, Idler, NO.1
2018-12 → 2023-10
ended
|
2NRVE F850 | — | |
| 16620 — Tensioner Assy, V-ribbed Belt | ||||
| 16620-BZ010 |
Tensioner Assy, V-ribbed Belt
2018-12 → 2023-10
ended
|
2NRVE F850 | — | |
No quantity column: the factory catalogue records which parts a vehicle
takes, never how many.
