Toyota Rush
2018-12 → 2023-10 · chassis F850 · catalogue 617310 · General
Supported model
Data version 2018-11
| Part number | Description | Fitment | Price | |
|---|---|---|---|---|
| 32000 — Converter Assy, Torque | ||||
| 32000-B1150 |
Converter Assy, Torque
2018-12 → 2023-10
ended
|
F850 | — | |
| 32101 — Gear Sub-assy, Drive Plate & Ring | ||||
| 32101-BZ070 |
Gear Sub-assy, Drive Plate & Ring
2018-12 → 2023-10
ended
|
F850 | — | |
| 32101A — Bolt(FOR DRIVE PLATE & TORQUE CONVERTER SETTING) | ||||
| 90041-05273 note |
Bolt(FOR DRIVE PLATE & TORQUE CONVERTER SETTING)
2018-12 → 2020-10
ended
|
F850 | — | |
| 90041-05281 note |
Bolt(FOR DRIVE PLATE & TORQUE CONVERTER SETTING)
2018-12 → 2020-10
ended
|
F850 | — | |
| 90041-05595 note |
Bolt(FOR DRIVE PLATE & TORQUE CONVERTER SETTING)
2020-11 → 2023-10
ended
|
F850 | — | |
| 90041-05596 note |
Bolt(FOR DRIVE PLATE & TORQUE CONVERTER SETTING)
2020-11 → 2023-10
ended
|
F850 | — | |
| 32101C — Bolt, Hexagon(FOR DRIVE PLATE SETTING) | ||||
| 9004A-10200 |
Bolt, Hexagon(FOR DRIVE PLATE SETTING)
2018-12 → 2023-10
ended
|
F850 | — | |
| 32111A — Plate(FOR PUMP IMPELLER DRIVE PLATE) | ||||
| 32113-BZ030 |
Plate(FOR PUMP IMPELLER DRIVE PLATE)
2018-12 → 2023-10
ended
|
F850 | — | |
| 35301 — Body Sub-assy, Front Oil Pump | ||||
| 35310-B1050 |
Body Sub-assy, Front Oil Pump
2018-12 → 2023-10
ended
|
F850 | — | |
| 35301A — Seal, Oil (FOR FRONT OIL PUMP) | ||||
| 90043-11336 |
Seal, Oil (FOR FRONT OIL PUMP)
2018-12 → 2023-10
ended
|
F850 | — | |
| 35301B — Ring, O (FOR FRONT OIL PUMP BODY) | ||||
| 90043-01161 |
Ring, O (FOR FRONT OIL PUMP BODY)
2018-12 → 2023-10
ended
|
F850 | — | |
| 35301F — Bolt (FOR FRONT OIL PUMP SETTING) | ||||
| 90041-05122 |
Bolt (FOR FRONT OIL PUMP SETTING)
2018-12 → 2023-10
ended
|
F850 | — | |
| 35617 — Ring, Clutch Drum Oil Seal | ||||
| 35653-B1010 |
Ring, Clutch Drum Oil Seal
2018-12 → 2023-10
ended
|
F850 | — | |
No quantity column: the factory catalogue records which parts a vehicle
takes, never how many.
