Toyota Rush
2018-12 → 2023-10 · chassis F850 · catalogue 617310 · General
Supported model
Data version 2018-11
Dashed callouts are standard fasteners the factory draws but does not list
as separate parts — there is no part number behind them.
| Part number | Description | Fitment | Price | |
|---|---|---|---|---|
| 81530B — Bulb, Rear Turn Signal Lamp | ||||
| 9004A-81019 note |
Bulb, Rear Turn Signal Lamp
2018-12 → 2023-10
ended
|
F850 | — | |
| 81550 — Lamp Assy, Rear Combination, RH | ||||
| 81550-BZ420 |
Lamp Assy, Rear Combination, RH
2018-12 → 2023-10
ended
|
F850 | — | |
| 81550E — Clip(FOR REAR COMBINATION LAMP) | ||||
| 81559-B2020 |
Clip(FOR REAR COMBINATION LAMP)
2018-12 → 2023-10
ended
|
F850 | — | |
| 81550N — Bulb, Back UP Lamp | ||||
| 9004A-81020 |
Bulb, Back UP Lamp
2018-12 → 2023-10
ended
|
F850 | — | |
| 81551D — Lens & Body, Rear Combination Lamp, RH | ||||
| 81551-BZ320 |
Lens & Body, Rear Combination Lamp, RH
2018-12 → 2023-10
ended
|
F850 | — | |
| 81555 — Socket & Wire Sub-assy, Rear Combination Lamp, RH | ||||
| 81555-BZ160 |
Socket & Wire Sub-assy, Rear Combination Lamp, RH
2018-12 → 2023-10
ended
|
F850 | — | |
| 81555A — Socket & Wire Sub-assy, Rear Combination Lamp, RH | ||||
| 81585-BZ020 |
Socket & Wire Sub-assy, Rear Combination Lamp, RH
2018-12 → 2023-10
ended
|
F850 | — | |
| 81560 — Lamp Assy, Rear Combination, LH | ||||
| 81560-BZ360 |
Lamp Assy, Rear Combination, LH
2018-12 → 2023-10
ended
|
F850 | — | |
| 81561D — Lens & Body, Rear Combination Lamp, LH | ||||
| 81561-BZ320 |
Lens & Body, Rear Combination Lamp, LH
2018-12 → 2023-10
ended
|
F850 | — | |
| 81565 — Socket & Wire Sub-assy, Rear Combination Lamp, LH | ||||
| 81555-BZ160 |
Socket & Wire Sub-assy, Rear Combination Lamp, LH
2018-12 → 2023-10
ended
|
F850 | — | |
| 81565A — Socket & Wire Sub-assy, Rear Combination Lamp, LH | ||||
| 81585-BZ020 |
Socket & Wire Sub-assy, Rear Combination Lamp, LH
2018-12 → 2023-10
ended
|
F850 | — | |
| 81580D — Lamp Assy, Rear, RH | ||||
| 81580-BZ070 |
Lamp Assy, Rear, RH
2018-12 → 2023-02
ended
|
F850 | — | |
| 81580-BZ071 |
Lamp Assy, Rear, RH
2023-03 → 2023-10
ended
|
F850 | — | |
| 81581C — Lens And Body, Rear Lamp, RH | ||||
| 81581-BZ040 |
Lens And Body, Rear Lamp, RH
2018-12 → 2023-10
ended
|
F850 | — | |
| 81584 — Packing, Rear Lamp RH | ||||
| 81582-BZ020 |
Packing, Rear Lamp RH
2018-12 → 2023-03
ended
|
F850 | — | |
| 81582-BZ080 |
Packing, Rear Lamp RH
2023-03 → 2023-10
ended
|
F850 | — | |
| 81590A — Lamp Assy, Rear, LH | ||||
| 81590-BZ080 |
Lamp Assy, Rear, LH
2018-12 → 2023-02
ended
|
F850 | — | |
| 81590-BZ081 |
Lamp Assy, Rear, LH
2023-03 → 2023-10
ended
|
F850 | — | |
| 81591B — Lens And Body, Rear Lamp, LH | ||||
| 81591-BZ040 |
Lens And Body, Rear Lamp, LH
2018-12 → 2023-10
ended
|
F850 | — | |
| 81594B — Packing, Rear Lamp LH | ||||
| 81592-BZ020 |
Packing, Rear Lamp LH
2018-12 → 2023-03
ended
|
F850 | — | |
| 81592-BZ080 |
Packing, Rear Lamp LH
2023-03 → 2023-10
ended
|
F850 | — | |
No quantity column: the factory catalogue records which parts a vehicle
takes, never how many.
