Toyota Rush
2018-12 → 2023-10 · chassis F850 · catalogue 617310 · General
Supported model
Data version 2018-11
Dashed callouts are standard fasteners the factory draws but does not list
as separate parts — there is no part number behind them.
| Part number | Description | Fitment | Price | |
|---|---|---|---|---|
| 82600 — Block Assy, Fuse | ||||
| 82600-BZ860 |
Block Assy, Fuse
2018-12 → 2023-10
ended
|
F850 | — | |
| 82616 — Puller, Fuse | ||||
| 82616-58010 |
Puller, Fuse
2018-12 → 2023-10
ended
|
F850 | — | |
| 82673B — Bracket, Junction Block, NO.2 | ||||
| 82673-BZ060 |
Bracket, Junction Block, NO.2
2018-12 → 2023-10
ended
|
F850 | — | |
| 84340 — Switch Assy, Stop Lamp | ||||
| 84340-B2060 |
Switch Assy, Stop Lamp
2018-12 → 2019-06
ended
|
F850 | — | |
| 84340-B2061 |
Switch Assy, Stop Lamp
2019-07 → 2023-10
ended
|
F850 | — | |
| 84345 — Adjuster, Stop Lamp Switch Mounting | ||||
| 84345-BZ020 |
Adjuster, Stop Lamp Switch Mounting
2018-12 → 2023-10
ended
|
F850 | — | |
| 84380 — Switch Assy, Brake Warning Test | ||||
| 84380-87Z06 |
Switch Assy, Brake Warning Test
2018-12 → 2023-10
ended
|
F850 | — | |
| 85916D — Relay, Fog Lamp | ||||
| 9004A-98013 |
Relay, Fog Lamp
2018-12 → 2023-10
ended
|
F850 EXT | — | |
| 88630Y — Relay, Rear Cooler | ||||
| 9004A-98006 |
Relay, Rear Cooler
2018-12 → 2023-10
ended
|
F850 | — | |
| 89661B — Computer, Engine Control | ||||
| 89261-B0010 |
Computer, Engine Control
2018-12 → 2023-10
ended
|
F850 | — | |
No quantity column: the factory catalogue records which parts a vehicle
takes, never how many.
