Toyota Rush
2018-12 → 2023-10 · chassis F850 · catalogue 617310 · General
Supported model
Data version 2018-11
Dashed callouts are standard fasteners the factory draws but does not list
as separate parts — there is no part number behind them.
| Part number | Description | Fitment | Price | |
|---|---|---|---|---|
| 88301 — Rotor Sub-assy, Magnet Clutch | ||||
| 88412-BZ110 |
Rotor Sub-assy, Magnet Clutch
2018-12 → 2023-10
ended
|
F850 | — | |
| 88302B — Stator, Magnet Clutch | ||||
| 88411-BZ190 |
Stator, Magnet Clutch
2018-12 → 2023-10
ended
|
F850 | — | |
| 88320 — Compressor Assy, Cooler | ||||
| 88320-BZ290 |
Compressor Assy, Cooler
2018-12 → 2023-10
ended
|
F850 | — | |
| 88329E — Bolt, Compressor, NO.1 | ||||
| 9004A-10144 |
Bolt, Compressor, NO.1
2018-12 → 2023-10
ended
|
F850 | — | |
| 88329F — Bolt, Compressor, NO.2 | ||||
| 9004A-10146 |
Bolt, Compressor, NO.2
2018-12 → 2023-10
ended
|
F850 | — | |
| 88335 — Gasket Kit, Overhaul | ||||
| 88335-14020 |
Gasket Kit, Overhaul
2018-12 → 2023-10
ended
|
F850 | — | |
| 88365 — Ring, Snap | ||||
| 90099-07125 |
Ring, Snap
2018-12 → 2023-10
ended
|
F850 | — | |
| 88365A — Ring, Snap (FOR COMPRESSOR) | ||||
| 90099-07114 |
Ring, Snap (FOR COMPRESSOR)
2018-12 → 2023-10
ended
|
F850 | — | |
| 88403 — Hub Sub-assy, Magnet Clutch | ||||
| 88403-BZ080 |
Hub Sub-assy, Magnet Clutch
2018-12 → 2023-10
ended
|
F850 | — | |
| 88410 — Clutch Assy, Magnet | ||||
| 88410-BZ300 |
Clutch Assy, Magnet
2018-12 → 2023-10
ended
|
F850 | — | |
| 88431 — Bracket, Compressor Mounting, NO.1 | ||||
| 88431-BZ130 |
Bracket, Compressor Mounting, NO.1
2018-12 → 2023-10
ended
|
F850 | — | |
| 88446C — Bolt, Magnet Clutch Setting | ||||
| 90099-04349 |
Bolt, Magnet Clutch Setting
2018-12 → 2023-10
ended
|
F850 | — | |
| 88688N — Bracket, Cooler | ||||
| 88688-BZ200 |
Bracket, Cooler
2018-12 → 2023-10
ended
|
F850 | — | |
No quantity column: the factory catalogue records which parts a vehicle
takes, never how many.
