Toyota Liteace
2022-05 → present · chassis S403 · catalogue 641230 · General
Supported model
Data version 2022-04
Seat Belt
24 part groups · 4 illustrations
Part groups
| PNC | Description |
|---|---|
| 73210 | Belt Assy, Front Seat Outer, RH |
| 73220 | Belt Assy, Front Seat Outer, LH |
| 73223B | Cover, Front Seat Belt Retractor, RH |
| 73223E | Clip, Rear Seat Belt Retractor Cover |
| 73224 | Cover, Front Seat Belt Retractor, LH |
| 73230 | Belt Assy, Front Seat Inner, RH |
| 73237A | Cover, Shoulder Belt Anchor |
| 73237B | Cover, Shoulder Belt Anchor |
| 73240 | Belt Assy, Front Seat Inner, LH |
| 73330G | Belt Assy, RR Seat Lap Type |
| 73360 | Belt Assy, Rear Seat 3 Point Type, Outer RH |
| 73360B | Belt Assy, Rear Seat, Outer |
| 73370 | Belt Assy, Rear Seat 3 Point Type, Outer LH |
| 73370B | Belt Assy, Rear Seat, Outer |
| 73380C | Belt Assy, Rear NO.1 Seat, Inner RH |
| 73380D | Belt Assy, Rear Seat, Inner |
| 73390C | Belt Assy, Rear NO.1 Seat, Inner LH |
| 73431 | Cover, Rear Seat Belt Retractor, RH |
| 73431A | Cover, Rear Seat Belt Retractor |
| 73432 | Cover, Rear Seat Belt Retractor, LH |
| 73530A | Belt Assy, Rear NO.2 Seat Lap Type, RH |
| 73580 | Belt Assy, Rear NO.2 Seat, Inner RH |
| 73580A | Belt Sub Assy, Rear NO.2 Seat, Inner |
| 73590 | Belt Assy, Rear NO.2 Seat, Inner LH |
PNC is the six-character part-group number the factory catalogue files
parts under. Every part on a drawing belongs to one.
