Toyota Townace

2022-01 → present · chassis S403 · catalogue 642210 · General

Supported model Data version 2022-11

Parts groups Model variants Characteristics Frame ranges Catalogue groups Illustration notes Newest parts Spec codes

Seat & Seat Track

139 part groups · 5 illustrations

Illustrations

Part groups

PNC	Description
71013S	Frame Sub-assy, Front Seatback, RH
71014S	Frame Sub-assy, Front Seatback, LH
71071S	Cover, Front Seat Cushion, RH(FOR SEPARATE TYPE)
71072S	Cover, Front Seat Cushion, LH(FOR SEPARATE TYPE)
71073S	Cover, Front Seatback, RH(FOR SEPARATE TYPE)
71074S	Cover, Front Seatback, LH(FOR SEPARATE TYPE)
71076S	Cover, Rear Seat Cushion, LH (FOR SEPARATE TYPE)
71393	Band, Rear Seat Cushion
71393A	Band, Rear Seat Cushion, RH
71393B	Band, Rear Seat Cushion, LH
71460S	Cushion Assy, Rear Seat, RH(FOR SEPARATE TYPE)
71470S	Cushion Assy, Rear Seat, LH (FOR SEPARATE TYPE)
71485C	Cover, Rear Seat Hinge, RH
71485D	Cover, Rear Seat Hinge, LH
71511S	Pad, Front Seat Cushion, RH(FOR SEPARATE TYPE)
71512S	Pad, Front Seat Cushion, LH (FOR SEPARATE TYPE)
71521	Pad, Front Seat Cushion Silencer, A
71522A	Pad, Front Seat Cushion Silencer, B
71537C	Protector, Front Seat Cushion Edge, RH
71537D	Protector, Front Seat Cushion Edge, LH
71551S	Pad, Front Seatback, RH(FOR SEPARATE TYPE)
71552S	Pad, Front Seatback, LH(FOR SEPARATE TYPE)
71553B	Pad, Front Seatback, B
71610S	Spring Assy, Front Seat Cushion, RH(FOR SEPARATE TYPE)
71620S	Spring Assy, Front Seat Cushion, LH(FOR SEPARATE TYPE)
71811C	Cover, Reclining Adjuster, RH
71811D	Shield, Front Seat Cushion, RH
71812C	Cover, Reclining Adjuster, LH
71812D	Shield, Front Seat Cushion, LH
7181C	Ring, Hog, Small (FOR FRONT SEATBACK)
7181CA	Ring, Hog, Small (FOR FRONT SEATBACK)
7181CB	Ring, Hog, Small (FOR FRONT SEAT CUSHION)
7181CC	Ring, Hog, Small (FOR FRONT SEAT CUSHION)
7181CD	Ring, Hog, Small (FOR REAR SEATBACK)
7181CE	Ring, Hog, Small (FOR REAR SEATBACK)
7181CF	Ring, Hog, Small (FOR REAR SEAT CUSHION)
7181CG	Ring, Hog, Small (FOR REAR SEAT CUSHION)
71831D	Cover, Front Seat Hinge, RH
71832B	Cover, Front Seat Hinge, LH
71833A	Cover, Rear Seat Reclining, NO.1 RH
71833B	Clip (FOR REAR SEAT RECLINING COVER)
71833D	Cover Rear Seat Reclining, RH
71833H	Cover, Rear Seat Reclining, NO.1 RH
71834A	Cover, Rear Seat Reclining, NO.1 LH
71834D	Cover, Rear Seat Reclining, LH
71834H	Cover, Rear Seat Reclining, NO.1 LH
71843B	Clip, Rear Seat Reclining Cover
71844D	Cover, Rear Seat Reclining, LH (FOR LH SEAT)
71844E	Cover, Rear Seat Reclining, RH (FOR LH SEAT)
71875A	Cover, Reclining Adjuster Inside, RH
71876	Cover, Reclining Adjuster Inside, LH
71903	Catch Sub-assy, Seat Cushion, Front
71910A	Headrest Assy, Front Seat
71910B	Headrest Assy, Front Seat
71930A	Support Assy, Front Seat Headrest
71930B	Support Assy, Rear Seat Headrest
71930C	Support, Front Seat Headrest, LH
71931	Support, Front Seat Headrest
71931B	Support Assy, Rear NO.1 Seat Headrest
71935	Clip
71936	Clip
71940A	Headrest Assy, Rear Seat
71956A	Support, Front Seat Headrest
71970	Headrest Assy, Rear Seat
71970B	Support Assy, Rear Seat Headrest, RH
71990A	Support Assy, Rear Seat Headrest, LH
72019	Retainer Sub-assy, Seat Track, Rear RH
72019A	Retainer Sub-assy, Seat Track, Rear LH
72065	Belt Sub-assy, Rear Seat Hook, RH
72066	Belt Sub-assy, Rear Seat Hook, LH
72110A	Track Assy, Front Seat, Outer RH
72120	Track Assy, Front Seat, Outer LH
72130A	Track Assy, Front Seat, Inner RH
72137C	Cover, Seat Track Inner, RH
72137G	Cover, Seat Track, Outer RH
72138	Cover, Seat Track, Outer LH
72138E	Cover, Seat Track, Inner LH
72140A	Track Assy, Front Seat,Inner LH
72213B	Knob, Seat Track Adjusting Handle, RH
72213C	Knob, Seat Track Adjusting Handle, LH
72213D	Knob, Seat Track Adjusting Handle
72301A	Wire Sub-assy, Seat Track Equalizing, RH
72301D	Wire Sub-assy, Seat Track Equalizing, LH
72507B	Handle Sub-assy, Reclining Release, RH
72507C	Handle Sub-assy, Reclining Release, LH
72525A	Handle, Reclining Adjuster Release, RH
72525B	Handle, Reclining Adjuster Release, RH
72526	Handle, Reclining Adjuster Release, LH
72526A	Handle, Reclining Adjuster Release, LH
72551A	Cover, Reclining Hinge
72551B	Cover, Reclining Hinge, RH
72551E	Cover, Reclining Hinge, RH
72552A	Cover, Reclining Hinge, LH
72552B	Cover, Reclining Hinge, LH
72552E	Cover, Reclining Hinge, LH
72553A	Protector, Reclining Cover, RH
72553C	Protector, Reclining Cover, RH
72554A	Protector, Reclining Cover, LH
72554B	Protector, Reclining Cover, LH
72637E	Handle, Rear Seat Lock, RH
72638	Handle, Rear Seat Lock, LH
72657	Silencer, Rear Seatback Lock Control Rod
72691A	Striker, Rear Seat Cushion Lock, NO.1
72691B	Striker, Rear Seat Cushion Lock
72692	Striker, Rear Seat Cushion Lock, NO.2
72693A	Striker, Rear Seat Cushion Lock, NO.3
72695	Silencer, Rear Seatback Lock Control Rod
72927D	Clip (FOR REAR SEAT CUSHION UNDER COVER)
72928D	Clip (FOR REAR SEAT CUSHION UNDER COVER)
78899	Bolt, Front Seat
79011	Cover Sub-assy, NO.1 Seat Cushion, RH
79011A	Cover Sub-assy, NO.1 Seat Cushion
79012	Cover Sub-assy, NO.1 Seat Cushion, LH
79013	Cover Sub-assy, NO.1 Seatback, RH
79014	Cover Sub-assy, NO.1 Seatback, LH
79103A	Frame Sub-assy, NO.1 Seatback, RH
79104	Frame Sub-assy, NO.1 Seatback, LH
79117C	Cover, NO.1 Seat Cushion, LH
79135A	Pad, NO.1 Seat Cushion, RH
79136B	Pad, NO.1 Seat Cushion, LH
79175	Pad, NO.1 Seatback
79175E	Pad, NO.1 Seatback, RH
79185	Pad, NO.1 Seatback, LH
79187	Cover, NO.1 Seat Inner Bracket
79187A	Cover, NO.1 Seat Inner Bracket, LH
79951	Cover, NO.1 Seat Cushion
79956B	Cover, Rear Seat Leg Side, RH
79956C	Cover, Rear Seat Leg Side, LH
79956S	Cover, Rear Seat Leg Side
79956T	Cover, Rear Seat Leg Side
79959	Cover, RR Seat Leg
79959A	Cover, Rear Seat Leg, RH
79959B	Cover, Rear Seat Leg, LH
79959C	Cover, Rear Seat Leg
79965	Cover, Rear Seat Leg Side, NO.2
79965A	Cover, Rear Seat Leg Side, NO.2
79965E	Cover, Rear Seat Leg Side, NO.2 Inner, RH
79965G	Cover, Rear Seat Leg Side, NO.2 Inner, LH
82666M	Holder, Connector

PNC is the six-character part-group number the factory catalogue files parts under. Every part on a drawing belongs to one.
