Toyota Liteace Van Wagon
1992-01 → 2000-07 · chassis CR27,KR2#,YR2#,39 · catalogue 651340 · General
Discontinued model
Data version 2001-01
Side Window
110 part groups · 6 illustrations
Part groups
| PNC | Description |
|---|---|
| 56117B | Dam, Window Glass Adhesive(FOR SLIDE DOOR) |
| 56117C | Dam, Window Glass Adhesive(FOR REAR SIDE) |
| 62113B | Glass, Side Front Window, Rear RH |
| 62119 | Packing, Side Front Window, RH |
| 62128 | Packing, Side Front Window, LH |
| 62211E | Glass, Side Window, Rear RH |
| 62221E | Glass, Side Window, Front LH |
| 62229 | Packing, Side Window |
| 62229A | Packing, Side Window, NO.2 |
| 62229B | Packing, Side Window, NO.3 |
| 62229C | Packing, Side Window |
| 62232B | Channel, Side Window Glass |
| 62232C | Channel, Side Window Glass, Front LH |
| 62232D | Channel, Side Window Glass, RH |
| 62232E | Channel, Side Window Glass, LH |
| 62249 | Plate, Side Window, RH |
| 62249A | Plate, Side Window, LH |
| 62253 | Weatherstrip, Side Window, Center |
| 62253A | Weatherstrip, Side Window, Center RH |
| 62253B | Weatherstrip, Side Window, Center LH |
| 62254E | Weatherstrip, Side Window, Center NO.2 |
| 62269 | Film, Side Window Frame, RH |
| 62269A | Film, Side Window Frame, LH |
| 62269C | Film, Side Window Frame, RH |
| 62269D | Film, Side Window Frame, LH |
| 62279A | Spacer, Side Window Frame |
| 62279B | Spacer, Side Window Frame, LH |
| 62279C | Spacer, Side Window Frame, RH |
| 62279D | Spacer, Side Window Frame, LH |
| 62281 | Glass, Slide Door Window, Front RH |
| 62287 | Glass, Slide Door Window, Rear RH |
| 62288 | Glass, Slide Door Window, Rear LH |
| 62346A | Packing, Slide Door Window, LH |
| 62375B | Clip, Side Window, NO.1 |
| 62375D | Clip, Side Window, NO.1 |
| 62377A | Clip, Side Window, NO.3 |
| 62377C | Clip, Side Window, NO.3 |
| 62378 | Clip, Door Window Glass |
| 62378B | Clip, Side Window, NO.4 |
| 62391A | Stopper, Side Window, NO.1 Front RH |
| 62391B | Stopper, Side Window, NO.1 Front LH |
| 62391C | Stopper, Side Window, NO.1 RH |
| 62391D | Stopper, Side Window, NO.1 LH |
| 62707A | Frame Sub-assy, Side Front Window, RH |
| 62708F | Frame Sub-assy, Side Front Window, LH |
| 62711K | Glass, Quarter Window, Front RH |
| 62712E | Glass, Side Front Window, LH |
| 62713K | Glass, Side Window, Rear RH |
| 62714B | Glass, Side Window, Rear LH |
| 62716A | Glass, Side Rear Window, LH |
| 62724E | Stop, Side Rear Window Glass, RH |
| 62725B | Stop, Side Window Glass, Rear NO.1 |
| 62729C | Pad, Rear Window Center Sash, RH |
| 62729D | Pad, Rear Window Center Sash, LH |
| 62729E | Pad, Rear Window Center Sash, RH |
| 62729F | Pad, Rear Window Center Sash, LH |
| 62731D | Hinge, Quarter Window, NO.1 |
| 62732 | Plate, Quarter OR Side Window Hinge Finish |
| 62732E | Hinge, Quarter Window, LH |
| 62732F | Plate, Rear Side Window Hinge Finish, LH |
| 62733D | Grass, Slide Door Window, Front LH |
| 62735 | Retainer, Quarter Window Hinge |
| 62735D | Retainer, Side Rear Window Hinge, RH |
| 62735E | Retainer, Side Rear Window Hinge, LH |
| 62740A | Window Assy, Side, Rear LH |
| 62741 | Weatherstrip, Quarter Window, RH |
| 62742 | Weatherstrip, Quarter Window, LH |
| 62744B | Weatherstrip, Side Rear Window, LH |
| 62746 | Weatherstrip, Side Window Glass Channel, NO.1 |
| 62746C | Weatherstrip, Side Window Glass, LH |
| 62746E | Weatherstrip, Side Window Glass, RH |
| 62746F | Weatherstrip, Side Window Glass, LH |
| 62751 | Stop, Side Window Fix Glass |
| 62751C | Stop, Side Window Fix Glass |
| 62751D | Stop, Slide Door Window Fix Glass, RH |
| 62751E | Stop, Slide Door Window Fix Glass, LH |
| 62754B | Weatherstrip, Side Front Window, Center NO.2 |
| 62754C | Weatherstrip, Side Front Window, Center NO.2 LH |
| 62754D | Weatherstrip, Side Front Window, Center NO.2 RH |
| 62754E | Weatherstrip, Side Front Window, Center NO.2 LH |
| 62755G | Run, Slide Door Window, RH |
| 62756B | Run, Slide Door Window, LH |
| 62757D | Protector, Side Window Glass |
| 62760 | Window Assy, Slide Door, LH |
| 62792A | Packing, Side Window Lock, RH |
| 62792B | Retainer, Side Window Lock |
| 62792D | Packing, Side Window Lock |
| 62793F | Retainer, Slide Door Window Lock, RH |
| 62798A | Moulding, Side Window, Front |
| 62885B | Guard, Quarter Window, NO.2 |
| 62910D | Lock Assy, Quarter Window |
| 62910G | Lock Assy, Side Rear Window, RH |
| 62920A | Lock Assy, Side Front Window, LH |
| 62920B | Lock Assy, Side Rear Window, LH |
| 62950 | Lock Assy, Side Rear Window |
| 67043D | Frame Sub-assy, Slide Door Window, RH |
| 67044D | Frame Sub-assy, Slide Door Window, LH |
| 67436A | Frame, Side Front Window, Center |
| 67436F | Frame, Side Front Window, Front Center LH |
| 67436G | Frame, Side Front Window, Center RH |
| 67436H | Frame, Side Front Window, Center LH |
| 67527 | Packing, Slide Door Window, RH |
| 67883D | Weatherstrip, Quarter Window, Rear |
| 67884D | Weatherstip, Side Window, Rear LH |
| 68113E | Glass, Rear Door, RH |
| 68114B | Glass, Rear Door, Front LH |
| 68141D | Run, Side Front Window, RH |
| 68142D | Run, Side Front Window, LH |
| 68163F | Weatherstrip, Slide Door Glass, RH |
| 68163G | Weatherstrip, Slide Door Glass, LH |
PNC is the six-character part-group number the factory catalogue files
parts under. Every part on a drawing belongs to one.
