Toyota Noah/Voxy

2014-01 → 2021-12 · chassis ZRR80 · catalogue 651380 · General

Supported model Data version 2023-05
Parts groups Model variants Characteristics Frame ranges Catalogue groups Illustration notes Newest parts Spec codes

Armrest & Visor

15 part groups · 2 illustrations

Illustrations

Figure 743784B 743784B 2014-01 → — Figure 743785C 743785C 2014-01 → —

Part groups

PNCDescription
74215A Base, Door Armrest RH
74216A Base, Door Armrest, LH
74231 Panel, Front Armrest Base, Upper RH
74232 Panel, Front Armrest Base, Upper LH
74310 Visor Assy, RH
74320 Visor Assy, LH
74348 Holder, Visor
74610A Grip Sub-assy, Assist
74612 Cover, Assist Grip
74637 Plug, Assist Grip, NO.2 RH
74638 Plug, Assist Grip, NO.2 LH
74680 Grip Assy, Pillar Assist
74811D Handle, Door Pull
74813B Handle, Front Door Pull, RH
74814C Handle, Front Door Pull, LH
PNC is the six-character part-group number the factory catalogue files parts under. Every part on a drawing belongs to one.
