Toyota Previa/Tarago
2006-01 → 2019-10 · chassis ACR50,GSR50 · catalogue 652260 · General
Supported model
Data version 2019-10
Front Bumper & Bumper Stay
30 part groups · 4 illustrations
Part groups
| PNC | Description |
|---|---|
| 52021 | Reinforcement Sub-assy, Front Bumper |
| 52029 | Reinforcement Sub-assy, Front Bumper, Upper |
| 52030 | Cover Assy, Front Bumper Hole, RH |
| 52040 | Cover Assy, Front Bumper Hole, LH |
| 52112D | Extension, Front Bumper, RH |
| 52113D | Extension, Front Bumper, LH |
| 52114A | Bracket, Front Bumper Extension Mounting |
| 52115A | Support, Front Bumper Side, RH |
| 52116A | Support, Front Bumper Side, LH |
| 52119A | Cover, Front Bumper |
| 52119D | Screw, NO.1 |
| 52127C | Cover, Front Bumper Hole |
| 52127D | Cover, Front Bumper Hole, RH |
| 52128B | Cover, Front Bumper Hole, LH |
| 52128C | Cover, Front Bumper Hole, LH |
| 52161C | Piece, Front Bumper |
| 52161T | Piece, Front Bumper |
| 52543 | Seal, Front Bumper Side, RH |
| 52543B | Seal, Front Bumper |
| 52544 | Seal, Front Bumper Side, LH |
| 52611 | Absorber, Front Bumper Energy |
| 52711 | Moulding, Front Bumper |
| 53112E | Grille, Radiator, Lower NO.1 |
| 53141H | Garnish, Radiator Grille |
| 53152B | Guide, Radiator Grille Air |
| 53155G | Seal, Radiator Grille |
| 81481C | Bracket, Fog Lamp |
| 81481E | Cover, Fog Lamp, RH |
| 81482C | Cover, Fog Lamp, LH |
| 89C48D | Retainer, Ultrasonic Sensor, Front Corner |
PNC is the six-character part-group number the factory catalogue files
parts under. Every part on a drawing belongs to one.
