Toyota Previa
2013-04 → 2016-05 · chassis AHR20 · catalogue 656250 · General
Supported model
Data version 2016-11
Roof Panel & Back Panel
25 part groups · 2 illustrations
Part groups
| PNC | Description |
|---|---|
| 61824D | Plate, Noise Control, NO.1 |
| 63071 | Frame Sub-assy, Back Door Opening, Upper |
| 63102A | Panel Sub-assy, Windshield Header |
| 63111 | Panel, Roof |
| 63142 | Reinforcement, Roof Panel, NO.2 |
| 63143B | Reinforcement, Roof Panel, NO.3 |
| 63144B | Reinforcement, Roof Panel, NO.4 |
| 63169B | Plate, Roof Panel Reinforcement, RH |
| 63179 | Plate, Roof Panel Reinforcement, LH |
| 63201C | Glass Sub-assy, Tilt Roof |
| 63203C | Housing Sub-assy, Tilt Roof |
| 63203D | Glass Sub-assy, Roof Window, NO.2 RH |
| 63203F | Housing Sub-assy, Sliding Roof |
| 63215G | Moulding, Moon Roof, Front |
| 63251K | Weatherstrip, Tilt Roof |
| 63256C | Seal, Tilt Roof Glass |
| 63258B | Seal, Removable Roof Glass, Inner |
| 63260A | Gear Sub-assy, Sliding Roof Drive |
| 63260C | Handle Assy, Tilt Roof Lock |
| 63282B | Striker, Tilt Roof Lock |
| 63619 | Cover, Tilt Roof Panel |
| 63851 | Bracket, Rear Slide Roof Housing, NO.1 RH |
| 63852 | Bracket, Rear Slide Roof Housing, NO.1 LH |
| 63853 | Bracket, Rear Slide Roof Housing, NO.2 RH |
| 63854 | Bracket, Rear Slide Roof Housing, NO.2 LH |
PNC is the six-character part-group number the factory catalogue files
parts under. Every part on a drawing belongs to one.
