Toyota Previa
2013-04 → 2016-05 · chassis AHR20 · catalogue 656250 · General
Supported model
Data version 2016-11
Rear Seat & Seat Track
128 part groups · 5 illustrations
Part groups
| PNC | Description |
|---|---|
| 55270B | Table Assy |
| 71015C | Frame Sub-assy, NO.1 Seat Cushion, RH |
| 71016B | Frame Sub-assy, NO.1 Seat Cushion, LH |
| 71033F | Leg Sub-assy, Rear Seat Cushion, RH |
| 71033G | Leg Sub-assy, Rear Seat Cushion, LH |
| 71324Q | Cushion, NO.1 Seat, LH |
| 71324S | Cushion, Rear NO.1 Seat, RH |
| 71465A | Spring, Rear Seat Cushion, NO.5 |
| 71499S | Damper, Seat Cushion Spring |
| 71693F | Cover, Rear NO.2 Seat Cushion Hinge, Lower RH NO.1 |
| 71693M | Cover, Rear Seat Cushion Hinge, Outer RH |
| 71694A | Cover, Rear NO.2 Seat Cushion Hinge, Lower LH NO.1 |
| 71694G | Cover, Rear Seat Cushion Hinge, Inner LH |
| 71695K | Protector, NO.1 Seatback, RH |
| 71695L | Protector, NO.1 Seatback, LH |
| 71695T | Protector, Rear Seat, NO.2 |
| 71696G | Protector, NO.2 Seatback, LH |
| 71833S | Cover, Rear Seat Reclining, NO.1 RH |
| 71833V | Cover, NO.1 Seat Reclining, NO.2 RH |
| 71834R | Cover, Rear Seat Reclining, LH |
| 71834S | Cover, Rear Seat Reclining, NO.1 LH |
| 71843K | Cover, Rear NO.2 Seat Reclining, NO.2 RH |
| 71844F | Cover, NO.2 Seat Reclining, NO.2 LH Inner |
| 71844G | Cover, NO.2 Seat Reclining, NO.2 LH Outer |
| 71844H | Cover, Rear Seat Reclining, NO.2 LH |
| 71875X | Cover, Reclining Adjuster Inside, RH |
| 71877K | Cover, Rear Seat Armrest Hole RH |
| 71877L | Cover, Rear Seat Armrest Hole LH |
| 71930K | Support Assy, NO.2 Seat Headrest, RH |
| 71930L | Support Assy, NO.2 Seat Headrest, LH |
| 71930Q | Support Assy, Rear Seat Headrest |
| 71930R | Support Assy, Rear NO.2 Seat Headrest, Center |
| 71930T | Support Assy, Rear Seat Legrest |
| 71940H | Headrest Assy, NO.2 Seat, RH |
| 71940J | Headrest Assy, NO.2 Seat, LH |
| 71940M | Headrest Assy, Rear Seat |
| 71960F | Headrest Assy, Rear NO.2 Seat, Center |
| 71H75F | Cover, Reclining Adjuster Inside, RH(FOR REAR NO.1 LH SEAT) |
| 71H76L | Cover, Reclining Adjuster Inside, LH NO.1(FOR RH SEAT) |
| 71H76N | Cover, Reclining Adjuster Inside, LH NO.1(FOR LH SEAT) |
| 71T76B | Cover, Reclining Adjuster Inside, LH |
| 72137Q | Cover, Rear Seat Track, NO.2 |
| 72137R | Cover, Rear Seat Track, NO.3 |
| 72210U | Cable Assy, NO.1 Seat Track Control, LH |
| 72210V | Cable Assy, NO.1 Seat Track Control, LH NO.1 |
| 72210W | Cable Assy, NO.1 Seat Track Control, LH NO.2 |
| 72210X | Cable Assy, NO.1 Seat Track Control, RH |
| 72210Y | Cable Assy, NO.1 Seat Track Control, RH NO.1 |
| 72210Z | Cable Assy, NO.1 Seat Track Control, RH NO.2 |
| 72507F | Handle Sub-assy, Rear Seat Reclining Release |
| 72525N | Handle, NO.1 Seat Reclining Adjuster Release, RH |
| 72526J | Handle, NO.1 Seat Reclining Adjuster Release, LH |
| 72551F | Cover, Reclining Link, RH NO.1 |
| 72551G | Cover, Reclining Link, RH NO.2 |
| 72552F | Cover, Reclining Link, LH NO.1 |
| 72552G | Cover, Reclining Link, LH NO.2 |
| 72553B | Protector, Reclining Cover, RH |
| 72553E | Protector, Reclining Cover, RH NO.1 |
| 72554 | Protector, Reclining Cover, LH |
| 72554E | Protector, Reclining Cover, LH NO.1 |
| 72554F | Protector, Reclining Cover, LH NO.2 |
| 72570E | Cable Assy, NO.1 Seat Reclining Adjusting, RH |
| 72570F | Cable Assy, NO.1 Seat Reclining Adjusting, LH |
| 72570G | Cable Assy, NO.2 Seat Reclining Adjusting, RH |
| 72570H | Cable Assy, NO.2 Seat Reclining Adjusting, LH |
| 72667E | Bezel, Rear Seatback Lock, Upper |
| 72679C | Bezel, Rear Seatback Lock Control |
| 72830V | Armrest Assy, Rear NO.1 Seat, RH |
| 72840K | Armrest Assy, Rear NO.1 Seat, LH |
| 72996G | Cover, Rear Seat, NO.2 RH |
| 72997F | Cover, Rear Seat, NO.2 LH |
| 73173P | Cover, Rear Seat Belt Hole, RH |
| 73174D | Cover, Rear Seat Belt Hole, LH |
| 73373U | Cover, NO.1 Seat Shoulder Belt, RH NO.1 |
| 73373V | Cover, NO.1 Seat Shoulder Belt, RH NO.2 |
| 73375N | Cover, Rear NO.1 Seat Shoulder Belt, LH NO.1 |
| 73375S | Cover, Rear NO.1 Seat Shoulder Belt, LH NO.2 |
| 76973F | Cover, Rear Under Side, RH |
| 76974F | Cover, Rear Under Side, LH |
| 78065A | Cover Sub-assy, Rear Seat Legrest, RH |
| 78065B | Cover Sub-assy, Rear Seat Legrest, LH |
| 78608C | Cable Sub-assy, Legrest Lock Control(FOR RH SEAT) |
| 78608D | Cable Sub-assy, Legrest Lock Control(FOR LH SEAT) |
| 78609A | Cover Sub-assy, Rear Seat Legrest Lock(FOR RH SEAT) |
| 78609B | Cover Sub-assy, Rear Seat Legrest Lock(FOR LH SEAT) |
| 78630A | Adjuster Assy, FR0NT Seat Side Table |
| 78632D | Cover, Rear Seat Side Table, NO.1 |
| 78632E | Cover, Rear Seat Side Table, NO.2 |
| 78632F | Clip, Rear Seat Side Table Cover |
| 78639B | Clip, Rear Seat Side Table |
| 78656J | Cover, Rear Seat Legrest, RH |
| 78656K | Cover, Rear Seat Legrest, LH |
| 78656N | Cover, Rear Seat Legrest, RH NO.2 |
| 78656P | Cover, Rear Seat Legrest, LH NO.2 |
| 78950F | Band Assy, Fold Seat Stopper, NO.1 |
| 78990B | Adjuster Assy, NO.1 Seat Footrest(FOR RH SEAT) |
| 78990C | Adjuster Assy, NO.1 Seat Footrest(FOR LH SEAT) |
| 79011B | Cover Sub-assy, NO.1 Seat Cushion, RH |
| 79012A | Cover Sub-assy, NO.1 Seat Cushion, LH |
| 79013D | Cover Sub-assy, NO.1 Seatback, RH |
| 79014B | Cover Sub-assy, NO.1 Seatback, LH |
| 79021D | Cover Sub-assy, NO.2 Seat Cushion, RH |
| 79022B | Cover Sub-assy, NO.2 Seat Cushion, LH |
| 79023D | Cover Sub-assy, NO.2 Seatback, RH |
| 79024D | Cover Sub-assy, NO.2 Seatback, LH |
| 79103B | Frame Sub-assy, NO.1 Seatback, RH |
| 79104A | Frame Sub-assy, NO.1 Seatback, LH |
| 79105G | Leg Sub-assy, NO.1 Seat, RH |
| 79106B | Leg Sub-assy, NO.1 Seat, LH |
| 79135C | Pad, NO.1 Seat Cushion, RH |
| 79136C | Pad, NO.1 Seat Cushion, LH |
| 79175F | Pad, NO.1 Seatback, RH |
| 79185A | Pad, NO.1 Seatback, LH |
| 79203B | Frame Sub-assy, NO.2 Seatback, RH |
| 79204C | Frame Sub-assy, NO.2 Seatback, LH |
| 79235F | Pad, NO.2 Seat Cushion, RH |
| 79245A | Pad, NO.2 Seat Cushion, LH |
| 79260C | Spring Assy, NO.2 Seat Cushion, RH |
| 79270B | Spring Assy, NO.2 Seat Cushion, LH |
| 79275F | Pad, NO.2 Seatback, RH |
| 79285C | Pad, NO.2 Seatback, LH |
| 79337A | Carpet, NO.2 Seat Cushion Under, RH |
| 79347A | Carpet, NO.2 Seat Cushion Under, LH |
| 79956V | Cover, Rear Seat Leg Side, RH |
| 79956W | Cover, Rear Seat Leg Side, LH |
| 79957D | Pad, Rear Seat Leg Side |
| 79959E | Cover, NO.1 Seat Leg, RH |
| 79959F | Cover, NO.1 Seat Leg, LH |
PNC is the six-character part-group number the factory catalogue files
parts under. Every part on a drawing belongs to one.
