Toyota RAV4 (CHINA)
2009-03 → 2013-07 · chassis ACA3# · catalogue 660310 · General
Supported model
Data version 2014-01
Dashed callouts are standard fasteners the factory draws but does not list
as separate parts — there is no part number behind them.
| Part number | Description | Fitment | Price | |
|---|---|---|---|---|
| 82151 — Wire, Front Door, RH | ||||
| 82151-0R050 |
Wire, Front Door, RH
2009-03 → 2011-08
ended
|
ACA37 | — | |
| 82151-0R060 |
Wire, Front Door, RH
2009-03 → 2011-08
ended
|
ACA33 | — | |
| 82151-0R080 |
Wire, Front Door, RH
2011-08 → —
|
ACA33 | — | |
| 82151-0R090 note |
Wire, Front Door, RH
2011-08 → 2013-03
ended
|
ACA33 | — | |
| 82151-0R090 |
Wire, Front Door, RH
2011-08 → —
|
ACA32,37 | — | |
| 82151-0R090 note |
Wire, Front Door, RH
2013-03 → —
|
ACA33 | — | |
| 82151-0R160 note |
Wire, Front Door, RH
2013-03 → —
|
ACA33 | — | |
| 82152 — Wire, Front Door, LH | ||||
| 82152-0R050 |
Wire, Front Door, LH
2009-03 → 2011-08
ended
|
ACA37 | — | |
| 82152-0R060 |
Wire, Front Door, LH
2009-03 → 2011-08
ended
|
ACA33 | — | |
| 82152-0R080 |
Wire, Front Door, LH
2011-08 → —
|
ACA33 | — | |
| 82152-0R090 note |
Wire, Front Door, LH
2013-03 → —
|
ACA33 | — | |
| 82152-0R090 |
Wire, Front Door, LH
2011-08 → —
|
ACA32,37 | — | |
| 82152-0R090 note |
Wire, Front Door, LH
2011-08 → 2013-03
ended
|
ACA33 | — | |
| 82152-0R180 note |
Wire, Front Door, LH
2013-03 → —
|
ACA33 | — | |
| 82153 — Wire, Rear Door, NO.1 | ||||
| 82153-0R020 |
Wire, Rear Door, NO.1
2009-03 → 2011-08
ended
|
ACA3# | — | |
| 82153-0R020 |
Wire, Rear Door, NO.1
2011-08 → —
|
ACA3# | — | |
| 82154 — Wire, Rear Door, NO.2 | ||||
| 82153-0R020 |
Wire, Rear Door, NO.2
2009-03 → 2011-08
ended
|
ACA3# | — | |
| 82153-0R020 |
Wire, Rear Door, NO.2
2011-08 → —
|
ACA3# | — | |
| 82184 — Wire, Back Door, NO.1 | ||||
| 82184-0R050 |
Wire, Back Door, NO.1
2009-03 → 2011-08
ended
|
ACA37 | — | |
| 82184-0R060 |
Wire, Back Door, NO.1
2009-03 → 2011-08
ended
|
ACA33 | — | |
| 82184-0R050 |
Wire, Back Door, NO.1
2011-08 → —
|
ACA32,37 | — | |
| 82184-0R050 note |
Wire, Back Door, NO.1
2011-08 → —
|
ACA33 | — | |
| 82184-0R060 note |
Wire, Back Door, NO.1
2011-08 → —
|
ACA33 | — | |
| 82184-0R110 |
Wire, Back Door, NO.1
2011-08 → —
|
ACA33 | — | |
| 82184-0R210 note |
Wire, Back Door, NO.1
2012-03 → 2013-03
ended
|
ACA33 | — | |
No quantity column: the factory catalogue records which parts a vehicle
takes, never how many.
